Pool Warehouse SUNRAY - Section 4: Installing Top Rails & Verticals; Attach Uprights and Top Ledges

No Diving or Jumping. Observe all Safety Rules.
4-1
A. Attach your Uprights and
Top Ledges (SUNRAY)
1. ContinuellingyourPool
a. Continuellingyourpoolwithwater.Donotputinmorethan12"(30cm)of
wateruntilthetoprailsandverticalcolumnsareallattached.
b. Keepworkingonthetoprailsandverticalcolumnswhilethepoollls.
• Seethedrawingonthenextpageforanoverviewofallthepartsusedto
installtheverticals,toprailsandtopconnectors.
2. InstalltheUprightsandLedges
a. Lineupthebottomofoneverticalcolumn(key1)with
thetabononebaseplate(key2).Thetabmustbeonthe
outsideoftheverticalcolumn.
b. Lineupthescrewholesandfastenwithoneself-tapping
screw(key3).
c. Placeatopconnector(key4)over
thetopedgeofthepoolwall(key
5)withthetabontheoutsideofthe
pool.Lineuptheholeinthetab
withthescrewholenearthetopof
theverticalcolumn.Thetabmustbe
on the outsideoftheverticalcol-
umn.Makesuretheverticalcolumn
isstraightupanddown.
d. Slideoneendofatoprail(key6)intothetopconnector.
e. Fastenthetopconnectortotheverticalcolumnwithoneself-tappingscrew(key
7).
f. Repeatthelastvestepsforeachoftheverticalcolumnsaroundthepoolwall.
Section
  PoolComponentInstallationManual
  InstallingtheTop
Rails&Verticals
Hint:
Use the ridges in the
poolwalltomakesure
theverticalcolumnis
straightupanddown.
1
4
1
3
2
2
4
6
5
7
