PoolMaster Pro Rebounder 72783 - Further Assembly Steps; Connect Support to Backboard and Hoop; Secure Upright Support in Base; Inflate Game Ball

Assembly Instructions
3
Step 6
•Use Ball Needle and a hand pump (not included) to inate
the Ball to 26 ½" circumference (approx. 8 ½" diameter).
Step 7
•Place "Warning! No Slam Dunking!" on base between
PVC Upright Supports.
poolmaster.com
•Remove the 2’’ pre-threaded Bolt from the U-Shaped
Upright and thread it through the front of the
backboard into the hole below the hoop bracket
and back into the bottom hole of the U-Shaped
backboard support and secure with hex nut.
•Attach the 3 ¼’’ bolt through the center hole in the
hoop bracket and into the top hole of the PVC
U-Shaped Support. Secure with hex nut.
Step 4
•Insert the U-Shaped Support into the Base. Fill Base
with water or sand and cover up opening with Cap.
•May need rubber mallet to push U-Shaped Upright
through Base opening.
Step 5
3 ¼" Bolt
2
" Bolt
Back View
2" Bolt 3 ¼" Bolt
Front View
