NOTICE: If not press and hold the operation switch on the front handle using switch trigger, the cable stops advance or retract,
no matter in forward or reverse rotation.
To advance cable,
Place the direction of forward/reverse lever in forward position.
Press and hold the operation switch on the front handle.
Then Squeeze and hold the switch trigger to advance the cable.
To retract cable
Place the direction of forward/reverse lever in reverse position.
Press and hold the operation switch on the front handle.
Then Squeeze and hold the switch trigger to retract the cable.
To advance and retracting the cable using the switch trigger.
UNPACK AND SET-UP(CONT.)
