OPERATION(CONT.)
The blade sharpening attachment is used for sharpening a wide range of blades, such as a mover blade, garden shovel or shears.
4. BLADE SHARPENING ATTACHMENT
4 Secure the blade with
a clamp and switch
the tool on.
6 Carefully lower the
grinding stone onto
the blade and slide
along the entire edge
of the blade.
NOTE:
1. To sharpen the blade, only a few passes are necessary.
2. Grinding stones (as pictured below) are recommended for
blade sharpening.
3 Screw the blade sharpening
attachment on the rotary tool
completely.
Remove the shaft collar.1
5 Rest the angled
surface of the
blade sharpening
attachment against
the under side of
the blade.
2 Loosen the collet nut with
spindle lock and wrench.
Insert grinding stone shank into
the collet then tighten the
collet nut with spindle lock and
wrench.
NOTICE: PLACING EXCESSIVE LOAD ON THE
ROTARY TOOL WHILE IT IS RUNNING AT LOW
SPEEDS MAY CAUSE IT TO OVERHEAT AND THE
MOTOR TO FAIL.
