PORT GUARD - Adjust Latch Backset; Bolt Alignment and Adjustment

Adjust the backset of latch (if needed)
Hold the bolt in front of the
door hole, with the latch face
A
Latch adjustmen t
(only if needed)
C
If the bolt holes are centered in the door hole, no adjustment
is required. Proceed to step 2. If the bolt holes are NOT
centered, adjust latch. See "bolt Adjustment."
B
60mm(2-3/8 in)
70mm(2-3/8 in)
60mm(2-3/8 in)
1
