48" TWO-SPEED PARTS
3$&.6
5(9,6,21
220/50 and 220/60 models require additional parts. Please contact Customer Service for assistance
21
# PART # DESCRIPTION # PART # DESCRIPTION
1 BASE-2K48 CADDY 21 N-516-NYLOK 5/16-18 NYLOK NUT FOR CASTERS
2 BELT2K-45-01 A-45 FAN BELT 22 PAC-PLB-01 BRASS INLET FITTING
3 BONNET-04 SPRAY BAR BONNET 23 PAC-PLB-02 BLACK PLUMBING ASSEMBLY
4 BOX-UL-02 2 SPD ELECTRICAL BOX 24 PAD6060/G PAD FOR 48” PAC (6 per unit)
5 BRACE-48-03 BRACE FOR BONNET 25 POWERCORD-01F ELECTRICAL POWER CORD
6 CASTERS-8 8” CASTERS 26 PRES-REG-01 WATER PRESSURE REGULATOR
7 CASTERS-8L 8” LOCKING CASTERS 27 PULLEY-3.25 3.25 MOTOR PULLEY
8 CTRL-2SPD-01 2 SPEED SWITCH SET 28 PUMP-016-4Z L/G 1/6HP SUBMERSIBLE PUMP
9 DRAIN-01 1/2” BOILER DRAIN VALVE 29 PVC-ADP-01 3/4” X 1/2” ADAPTER
10 FAN-ASSM-05 FAN BLADE ASSEMBLY FOR 48” UNIT 30 S-004 1/4-20 X 1/2” BOLT FOR FLOAT
11 FLAP-48-01 FRONT FLAP FOR 48” PAC 31 S-006 #12 X 1 1/4” TEK SCREW
12 FLOAT-02 FLOAT VALVE 32 S-007 5/16-18 TRUSS HEAD SCREW FOR CASTERS
13 FLOATSWITCH-01 WATER PUMP SHUT OFF SWITCH 33 S-009 10-24 X 3/4” TRUSS HEAD SCREW
14 HOSE-FF37 1/2” X 37” FEM/FEM HOSE PLB TO PUMP 34 SPRAY-08 SPRAY BAR FOR 48” PAC
15 HOSE-FF68 1/2” X 68” FEM/FEM HOSE SPRAY BAR TO PLB 35 SPRAY-ACC-04 CLAMP FASTENER 1029
16 HOSE-FM25 1/2” X 25” MALE/FEM HOSE INLET TO FLOAT 36 SWITCHPL-2SPD 2SPD SWITCH COVER PLATE
17 HOSE-FTG-05 FEM/FEM 3/4” X 3/4” SWIVEL 37 TROUGH-03 PAD TROUGH FOR 48” PAC
18 MESH-PAC-06 FAN SCREEN 38 UPRIGHTS-48 UPRIGHT FOR 48” UNIT
19 MOTOR-010-01 1HP/2SPD MOTOR FOR 48” UNIT 39 VALVE-01 1/2” GATE VALVE
20 MOTOR-MNT-48 MOTOR MOUNT FOR 48” UNIT 40 VENTURI-48-02 VENTURI FOR 48” PAC FAN ASSEMBLY
