No. 1535 PORTABLE ROLLAWAY BACKSTOP
ASSEMBLY INSTRUCTIONS
CAUTION
BEFORE rolling this portable backstop onto the finished floor, check
with the flooring manufacturer to ensure the finished floor will not be damaged
due to the weight of this unit. When fully-assembled, this backstop will weigh
as much as 2,525 pounds (1,145kg), and will exert a force of approximately
485 pounds per square inch (35kg per square centimeter). Optional items
(shot clock, etc.) will result in additional weight.
6
WARNING
THE SPRING-ACTIVATED MECHANISM ON THIS BACKSTOP MAY BE EXTREMELY DANGEROUS IF THESE
ASSEMBLY INSTRUCTIONS AND OPERATION PROCEDURES ARE NOT FOLLOWED STEP-BY-STEP. UNDER
NO CIRCUMSTANCES SHOULD THE SHIPPING CLAMP (SEE DETAIL “A” BELOW) BE REMOVED BEFORE
THE BACKBOARD, GOAL AND BACKBOARD YOKE FRAME ARE ASSEMBLED TO THE UNIT. FAILURE TO
FOLLOW THIS PROCEDURE COULD RESULT IN PROPERTY DAMAGE, INJURIES, OR EVEN DEATH. A
MINIMUM OF TWO, AND PREFERABLY THREE, INDIVIDUALS (TO HOLD AND MOUNT BACKBOARD) ARE
REQUIRED, FOR PROPER AND SAFE ASSEMBLY OF THIS UNIT.
Detail "A"
DO NOT
REMOVE THIS
SHIPPING CLAMP UNTIL
BACKBOARD AND GOAL ARE
MOUNTED ON UNIT
WARNING
To Next Page
