Potterton Derwent Compact Plus - Heat Exchanger Assembly

POTTERTON COMMERCIAL PRODUCTS DIVISION SECTION 7
INSTALLATION, OPERATION AND MAINTENANCE MANUAL
DERWENT COMPACT PLUS - CONDENSING
PAGE 27
Heat Exchanger Assembly
Item No. Description Qty Part No
1 Left Hand Section 1 S17800857
2 Right Hand Section 1 S17800847
3 Intermediate Section 1 S17804057
4 Flow Header (4 Sections)
Flow Header (6 Sections)
Flow Header (8 Sections)
1
1
1
S501407
S201409
S501411
5 Manifold Clamp Plate (4 Sections)
Manifold Clamp Plate (6 Sections)
Manifold Clamp Plate (8 Sections)
1
1
1
S131164
S131166
S131168
6 Extension 526 ½” L.50 1 S15922705
7 Bleed Tap ½” 1 S17006472
8 Flow Pipe (4 Sections)
Flow Pipe (6-8 Sections)
1
1
S17004722
S17004723
9 Elbow 1½” (6-8 Sections)
Elbow 1¼” (4 Sections)
1
1
S9125780
S15923012
10 Side Case Fixing Panel (6 Sections)
Side Case Fixing Panel (8 Sections)
Side Case Fixing Panel (4 Sections)
1
1
1
S131317
S131326
S137922
11 Rear Panel
Rear Panel
Rear Panel
1
1
1
S137636
S137692
S137703
12 Rear Panel Insulation (6 Sections)
Rear Panel Insulation (8 Sections)
Rear Panel Insulation (4 Sections)
1
1
1
S137745
S137746
S137929
13 Front Insulation (8 Sections)
Front Insulation (6 Sections)
Front Insulation (4 Sections)
1
1
1
S131812
S131814
S137932
14 Oburating Insulation 1 S133107
48 Bag of Fixings
