SECTION 7 POTTERTON COMMERCIAL PRODUCTS DIVISION
INSTALLATION, OPERATION AND MAINTENANCE MANUAL
PAGE 28
DERWENT COMPACT PLUS - CONDENSING
15 Insulation Strip (8 Sections)
Insulation Strip (6 Sections)
Insulation Strip (4 Sections)
1
1
1
S132564
S132566
S132568
16
16a
Thermostat Pocket
Spring Ref. 556557
1
1
S17001781
S17006459
17 Cap No.290 ¼” 8 x 13 1 S15926004
18 Base Tray (8 Sections)
Base Tray (6 Sections)
Base Tray (4 Sections)
1
1
1
S137586
S137587
S137767
19 Seal 24 x 16 x 3 – Blue 1 S501139
20 Pipe Clip Retaining Plate 1 S132735
21 Pipe Clip 1 S132814
22 Electronic Transformer Support 1 S131777
23 Jump Lead SIHT-VS 1.4 mm 1 S15825230
24 Ignition Cap 1 S500483
25 Transformer Wiring 1 S132406
26 Ceramic Felt Strip 30 x 3 3m SN9205350
27 Ceramic Felt Strip 20 x 3 3m SN9205320
28 Ceramic Sealing Strip (6-8 Sections)
Ceramic Sealing Strip (4 Sections)
1.50m
1.50m
SN9195370
S17000167
29 Tie Bar M10 x 450 (6 Sections)
Tie Bar M10 x 610 (8 Sections)
Tie Bar M10 x 300 (4 Sections)
1
1
1
SN9170990
SN9171010
S15243610
30 ‘O’ Ring Seals 1 SN9195220
31 Studs M10 x 120 1 S15245372
32 4 Entries Cable Locking System 1 S17076332
33 Strengthening Piece for Stability (4 Sections) 1 S136478
34 Condensor Backflow Tube (6-8 Sections)
Condensor Backflow Tube (4 Sections)
1
1
S137554
S137563
35 Boiler Backflow Tube (6-8 Sections)
Boiler Backflow Tube (4 Sections)
1
1
S137555
S137562
36 Seal 30 x 22 x 2 GEB 2064 1 S15625247
37 Diaphragm 15 dia.(4 Sections)
Diaphragm 16 dia. (6 Sections)
Diaphragm 19 dia. (8 Sections)
1
1
1`
S137879
S137880
S137881
38 Seal BA-U 38 x 27 x 2 (4 Sections)
Seal 44 x 32 x 2 (6-8 Sections)
1
1
S133221
S15600310
39 Condensor Heat Exchanger (6-8 Sections)
Condensor Heat Exchanger (4 Sections)
Condensor Heat Exchanger (6 Sections)
Condensor Heat Exchanger (8 Sections)
1
1
1
1
S15600310
S503498
S503499
S503500
40 Silicone Braid 7 dia. 1.50m S17000166
41 Drain Cock 1 S17006193
42 Cylindrical Link M-F 1 ¼” – ¾” 1 S137627
43 Siphon 1 S504100
44 + 46 Flexible Tubing ¾” – 1” L.960 (4-6 Sections)
Flexible Tubing M-F 1” L.960 (8 Sections)
1
1
S137560
S137557
45 + 47 Flexible Tubing ¾” – 1” L.1160 (4-6 Sections)
Flexible Tubing M-F 1” L.1160 (8 Sections)
1
1
S137561
S137558
48 Bag of Fixings 1 S504285
