Poulan Pro 193733 User Manual

28 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

SELF-PROPELLED ROTARY

LAWN MOWER

WARNING: This lawn mower is equipped with an internal com bus tion engine and

should not be used on or near any un im proved forest-covered, brush-covered or

grass-cov ered land unless the engine’s exhaust system is equipped with a spark

arrester meeting applicable local or state laws (if any). If a spark arrester is used, it

should be maintained in effective working order by the operator.

In the state of California the above is required by law (Section 4442 of the California

Public Resources Code). Other states may have similar laws. Federal laws apply

on federal lands. A spark arrester for the mufﬂ er is available through your nearest

authorized service center.

193733 Rev. 8 01.20.10 BY Printed in U.S.A.

Table of Contents

Questions and Answers:

M
marshallkatherineJul 28, 2025
How to fix loss of power in Poulan Pro 193733?
- J
  jocelyn75Jul 28, 2025
  If your Poulan Pro Lawn Mower is losing power, several factors could be the cause. It might be due to the mower housing or blade dragging in heavy grass, so try raising the cutting height. Also, check if you are cutting too much grass at once and raise the cutting height if needed. A dirty air filter, buildup of grass under the mower, too much oil in the engine, or walking too fast can also contribute to power loss. Clean or replace the air filter, clean the underside of the mower, check the oil level, and reduce your walking speed while cutting.
J
Joshua DennisAug 1, 2025
What to do if the starter rope is hard to pull on my Poulan Pro Lawn Mower?
- D
  donaldwilsonAug 1, 2025
  If the starter rope on your Poulan Pro Lawn Mower is hard to pull, it could be due to several reasons. First, make sure you depress the control bar to the upper handle before pulling the starter rope, as the engine flywheel brake might be engaged. Another possible cause is the blade dragging in the grass, so move the lawn mower to cut grass or to a hard surface. If this doesn't help, the blade adapter might be broken, and you would need to replace it.
J
Jennifer HartAug 6, 2025
What causes excessive vibration in Poulan Pro 193733?
- L
  Lauren TorresAug 6, 2025
  Excessive vibration in your Poulan Pro Lawn Mower could be due to a worn, bent, or loose blade. Try replacing the blade and tightening the blade bolt.
R
reginalongAug 10, 2025
Why is my Poulan Pro 193733 so hard to push?
- T
  Timothy MooreAug 10, 2025
  If your Poulan Pro Lawn Mower is hard to push, the grass might be too high, or the wheel height might be too low; try raising the cutting height. Another cause could be the rear of the mower housing or cutting blade dragging in the grass, in which case you should raise the rear of the mower housing one setting higher. Additionally, check if the grass catcher is too full and empty it if necessary. Finally, ensure that the handle height is right for you, and adjust it to suit your preference.
V
Vanessa WilliamsAug 14, 2025
How to fix an uneven cut with Poulan Pro 193733 Lawn Mower?
- C
  Chris PerryAug 15, 2025
  If your Poulan Pro Lawn Mower is producing an uneven cut, there are a few things you can check. The blade might be worn, bent, or loose, so replace the blade or tighten the blade bolt. Also, ensure that all wheel heights are set at the same level. Finally, a buildup of grass, leaves, and trash under the mower can cause an uneven cut, so clean the underside of the mower housing.
T
teresa51Aug 18, 2025
What causes loss of drive speed on a Poulan Pro 193733?
- C
  Carrie AndersonAug 19, 2025
  A loss of drive or slowing of drive speed in your Poulan Pro Lawn Mower can be attributed to several factors. The drive belt may be worn, so check and replace it if necessary. Alternatively, the belt might be off the pulley, so check and reinstall the drive belt. A worn or broken drive cable could also be the culprit, requiring replacement. Finally, a loose drive control system might be the cause, and you should adjust the drive control.
C
Charles CherryAug 23, 2025
Why is the grass catcher not filling on my Poulan Pro Lawn Mower?
- J
  Jennifer GarzaAug 23, 2025
  If the grass catcher on your Poulan Pro Lawn Mower is not filling, it could be due to several reasons. The cutting height might be too low, so try raising it. Also, the lift on the blade might be worn off, which means you'll need to replace the blade. Finally, the catcher might not be venting air properly, so clean the grass catcher to ensure proper airflow.

Poulan Pro 193733 Specifications

General

Engine Displacement	190 cc
Cutting Width	21 in
Drive System	Self-Propelled
Fuel Tank Capacity	1.6 qt
Cutting Height	1.25-3.75 in

Summary

Safety First

General Operation Safety

Guidelines for safe lawn mower operation and handling.

Slope Operation Safety

Precautions for mowing on slopes to prevent accidents.

Children and Gasoline Safety

Warnings regarding children's proximity and safe gasoline handling.

Lawn Mower Operation

Engine Speed and Cutting Height

How to control engine speed and adjust the cutting height.

Drive Control Systems Explained

Details on standard, dual bail, and autowalk drive controls.

Operator Presence Control Bar

Explains the safety function of the operator presence control bar.

Mulching and Discharge Modes

Maintenance Procedures

Maintenance Schedule

Engine and Filter Care

Blade Maintenance

Service and Adjustments

Adjusting Mower Handles

Drive Belt Replacement

Engine Adjustments

Troubleshooting Guide

Engine Starting Issues

Causes and corrections for engine starting problems.

Mowing Performance Problems

Drive System Issues
