OPERATOR'S MANUAL
MODEL:
XT19H42YT
LAWN TRACTOR
ALWAYS WEAR EYE PROTECTION DURING OPERATION
Visit our website: www.poulan-pro.com
WARNING:
Read this Man u al and follow all Warnings and
Safety Instructions. Fail ure to do so can re sult
in serious in ju ry.
IMPORTANT MANUAL Do Not Throw Away
402993 Rev.1 03.16.06 TR/VB
Printed in U.S.A.
03076

Table of Contents

Questions and Answers

  • C
    Carmen JonesAug 4, 2025
    Why Poulan Pro XT19H42YT engine will not turn over?
    • S
      Stephanie MatthewsAug 4, 2025
      If your Poulan Pro Lawn Mower engine won't turn over, make sure of the following: 1. Depress the brake pedal. 2. Disengage the attachment clutch. 3. Check the battery, it may be weak or dead - recharge or replace it. 4. Replace any blown fuses. 5. Clean corroded battery terminals. 6. Check for loose or damaged wiring. 7. Check or replace the ignition switch if faulty. 8. Check or replace the solenoid or starter if faulty. If the operator presence switch(es) are faulty, contact an authorized service center/department.
  • K
    Kelly RoyAug 8, 2025
    What to do if Poulan Pro Lawn Mower is hard to start?
    • M
      Marc Ware MDAug 9, 2025
      If your Poulan Pro Lawn Mower is hard to start, consider these possible causes: * A dirty air filter, which should be cleaned or replaced. * A bad spark plug, which should be replaced. * A weak or dead battery, which needs to be recharged or replaced. * A dirty fuel filter, which should be replaced. * Stale or dirty fuel, requiring you to empty and refill the tank with fresh, clean gasoline. * Loose or damaged wiring, which needs to be checked. For carburetor or engine valve adjustments, see the service adjustments section or contact an authorized service center/department.
  • J
    John WilliamsAug 13, 2025
    What to do if Poulan Pro Lawn Mower engine clicks but will not start?
    • O
      obakerAug 13, 2025
      If your Poulan Pro Lawn Mower engine clicks but won't start, the following could be the reasons: * The battery may be weak or dead, so recharge or replace it. * The battery terminals may be corroded; clean them. * There might be loose or damaged wiring; check all wiring. * The solenoid or starter could be faulty; check or replace them.
  • J
    Jessica WilsonAug 25, 2025
    Why Poulan Pro XT19H42YT has excessive vibration?
    • A
      Andrew GlennAug 25, 2025
      If your Poulan Pro Lawn Mower is excessively vibrating, consider these potential causes: * The blade may be worn, bent, or loose. Replace the blade and tighten the blade bolt. * The blade mandrel could be bent; replace it. * There might be loose or damaged parts. Tighten any loose parts and replace any damaged ones.
  • K
    Kathryn EllisOct 29, 2025
    How to fix a Poulan Pro Lawn Mower that will not start?
    • Q
      qrogersOct 29, 2025
      If your Poulan Pro Lawn Mower won't start, there are several potential causes: * The fuel tank may be empty, in which case you should fill it. * The engine may not be properly choked; refer to the “TO START ENGINE” section in the Operation section. * The engine might be flooded; wait a few minutes before trying again. * A bad spark plug could be the issue, so replace it. * A weak or dead battery may need recharging or replacing. * A dirty air filter should be cleaned or replaced. * A dirty fuel filter should be replaced. * Water in the fuel requires emptying the tank and carburetor, refilling with fresh gasoline, and replacing the fuel filter. * Loose or damaged wiring needs to be checked. For carburetor or engine valve adjustments, consult the service adjustments secti...
  • D
    David HendersonNov 18, 2025
    Why Poulan Pro Lawn Mower has loss of power?
    • J
      Juan BennettNov 18, 2025
      If your Poulan Pro Lawn Mower is experiencing a loss of power, here are several things to consider: * You might be cutting too much grass or going too fast; try raising the cutting height or reducing your speed. * Ensure the throttle isn't in the “CHOKE” position; adjust the throttle control. * Clean any grass, leaves, or trash buildup under the mower housing. * Check and clean/replace the air filter if it's dirty. * Check and correct the oil level or change the oil if it's low or dirty. * Inspect, clean, regap, or replace the spark plug if faulty. * Replace the fuel filter if it's dirty. * Empty and refill the fuel tank with fresh, clean gasoline if the fuel is stale or dirty. * Address water in the fuel by emptying the tank and carburetor, refilling with fresh gasoline...

Summary

SAFETY RULES

GENERAL OPERATION

Instructions for operating the lawn tractor safely and correctly.

SLOPE OPERATION

Guidelines for safely operating the tractor on slopes to prevent accidents.

CHILDREN

Safety precautions regarding children around the operating tractor.

TOWING

SAFE HANDLING OF GASOLINE

Precautions for safely handling and storing gasoline to prevent fire and explosion.

GENERAL SERVICE

CUSTOMER RESPONSIBILITIES

Read and Observe Safety Rules

Follow Maintenance Schedule

Spark Arrester Warning

Warning regarding the need for a spark arrester when operating near certain types of land.

OPERATION

Hazard Definitions

Definitions of DANGER, WARNING, CAUTION, and other hazard indicators.

KNOW YOUR TRACTOR

HOW TO USE YOUR TRACTOR

General guidance on operating the tractor and its main functions.

STOPPING

Procedures for safely stopping the mower blades, ground drive, and engine.

TO OPERATE MOWER

REVERSE OPERATION SYSTEM (ROS)

Explanation of the Reverse Operation System and its safe use.

TO TRANSPORT

TOWING CARTS AND OTHER ATTACHMENTS

BEFORE STARTING THE ENGINE

Essential checks and procedures before starting the tractor's engine.

ADD GASOLINE

Instructions for adding gasoline safely and correctly, including fuel type and storage.

TO START ENGINE

Detailed steps for starting the tractor engine, including warm and cold weather procedures.

PURGE TRANSMISSION

Procedure to purge air from the transmission for proper operation.

MOWING TIPS

MAINTENANCE

MAINTENANCE SCHEDULE

A schedule outlining required maintenance tasks and their frequency.

GENERAL RECOMMENDATIONS

BEFORE EACH USE

Daily checks and inspections to be performed before operating the tractor.

BRAKE OPERATION

Procedures and checks for ensuring the proper operation of the tractor's brakes.

OPERATOR PRESENCE AND REVERSE OPERATION SYSTEMS

Checks for the operator presence and Reverse Operation System (ROS) functionality.

BLADE CARE

BATTERY

TO CHANGE ENGINE OIL

SERVICE AND ADJUSTMENTS

TO REMOVE MOWER

TO INSTALL MOWER

TO LEVEL MOWER

FRONT-TO-BACK ADJUSTMENT

PRECISION SIDE-TO-SIDE ADJUSTMENT

TO REPLACE MOWER DRIVE BELT

TO REPLACE MOTION DRIVE BELT

TO CHECK BRAKE

TO START ENGINE WITH A WEAK BATTERY

Guidance on safely jump-starting the tractor with a weak battery.

REPLACING BATTERY

INTERLOCKS AND RELAYS

ADJUST CARBURETOR

TROUBLESHOOTING POINTS

Will not start

Common causes and corrections for the engine failing to start.

Hard to start

Troubleshooting steps for an engine that is difficult to start.

Engine will not turn over

Diagnosing issues when the engine does not crank or turn over.

Engine clicks but will not start

Troubleshooting when the engine makes a clicking sound but won't start.

Loss of power

Identifying causes and solutions for reduced engine power or performance.

Excessive vibration

Engine dies when tractor is shifted into reverse

Causes and fixes for the engine shutting off when shifting into reverse.

Engine continues to run when operator leaves seat with attachment clutch engaged

Troubleshooting faulty operator presence control system preventing shutdown.

Poor cut - uneven

Diagnosing and correcting issues that lead to an uneven lawn cut.

Mower blades will not rotate

Identifying reasons why the mower blades are not spinning.

Poor grass discharge

Battery will not charge

Loss of drive

Diagnosing issues related to the tractor losing its drive or propulsion.

Engine backfires when turning engine OFF

SUGGESTED GUIDE FOR SIGHTING SLOPES FOR SAFE OPERATION

Slope Measurement Guide

Instructions on how to use a fold-out guide to measure slope angles safely.

Poulan Pro XT19H42YT Specifications

General IconGeneral
EngineBriggs & Stratton
Cutting Width42 inches
TransmissionHydrostatic
Deck MaterialSteel
Cutting Height1.5 to 4 inches
Warranty3 years
