Power Climber Wind PC1 Series User Manual

40 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

WARNING:

Manufacturer: Power Climber® 365 Upland Drive, Seattle, WA 98188

Phone 800-560-2546, Fax 206-575-2535 © 2014

• All persons operating this equipment must read and completely understand this manual

• All persons must be thoroughly trained in the use of the equipment, its operational and safety

features, and they must also be capable of carrying out the daily inspections.

• Only authorized persons shall operate the equipment.

• Any operation in violation of these instructions is at the operator’s own risk and may result in

serious injuries.

• Keep this manual with the hoist at all times.

• Use only spare parts and recommended steel wire rope from Power Climber®.

• It is the responsibility of the user of this hoist to determine that this hoist is suitable to be used in conjunction

with any other equipment. The user must also determine that this hoist and additional components used will be

in strict conformity with the provisions of Federal, State, National, and local ordinances and regulations.

OPERATING INSTRUCTIONS

PC1 HOIST

Table of Contents

Questions and Answers:

K
kim72Aug 15, 2025
What to do if Power Climber Wind Chain Hoists have no power?
- A
  Angela HowardAug 15, 2025
  If your platform isn't getting power and the voltage indicator light is off, several issues could be the cause. It could be that the power at the junction box is off, a circuit breaker has tripped, the plugs aren't connected properly, the electrical cord is damaged, the power indicator light is burnt out, not enough power is being supplied to the hoist, or the thermal (TH2) has tripped due to excessive amperage. Consult with your supervisor to resolve these issues and check for low voltage.
L
Luke PittsAug 18, 2025
Why won't my Power Climber Wind Chain Hoists run, but the voltage light is on?
- G
  gleeAug 18, 2025
  If the hoist motor is hot, the motor thermal overload protection may have tripped. Allow the motor to cool down; it may take 30 minutes or longer for it to reset. Frequent stops and starts, high outside temperatures, a dragging brake, or overloading can cause the motor to heat up.

Power Climber Wind PC1 Series Specifications

General

Model	PC1 Series
Category	Chain Hoists
Chain Fall	1
Protection Class	IP55
Ambient Temperature	-20°C to +40°C
Voltage	400V, 3 Phase
Chain Size	7.1 mm

Summary

2.0 Instructions

2.1 General Specifications

2.3 Safety Summary

Offers essential safety information and warnings for operating the hoist.

2.6 Hoist Installation

Installing Hoist to Platform

3.0 Safety Instructions

3.1 Daily Tests

Details critical daily tests to ensure the hoist operates safely and correctly.

Testing Overspeed Brake

Explains how to test the overspeed brake function before each use.

Testing Overspeed Brake Test Button

Guides the user through testing the secondary overspeed brake activation.

Resetting the Overspeed Brake

Describes the procedure for resetting the overspeed brake after it has tripped.

Testing the Emergency Stop Button

Details how to verify the functionality of the emergency stop button.

Testing the Controlled Descent Feature

Explains the test for the controlled descent feature during power loss.

3.2 Daily Inspection

Lists components and checks required for a daily visual inspection of the hoist.

4.0 Hoist Operations

Testing the Emergency Stop Button

Instructions for testing the emergency stop button during routine operation.

4.3 Maintenance

4.4 Troubleshooting

Offers solutions for common problems encountered with the hoist.
