10 Powercraft
BELT SANDER
The numbers in the following text refer to the drawings on page 2
For your own safety and for the safety of others, please read these instructions
carefully before using this appliance. It will help you understand your product more
easily and avoid unnecessary risks. Keep this instruction manual in a safe place for
future use.
Contents
1. Machine data
2. Safety instructions
3. Operation
4. Maintenance
1. MACHINE DATA
Technical specifications
Productinformation
Fig. A + B
The belt sander is the perfect tool to sand wood and to grind iron, plastic or similar materials.
The belt sander must be used for the rough work, for the normal sanding work an orbital sander
must be used.
1. Rear handle
2. Front handle
3. Front belt roller
4. Clamping lever
5. Direction indicator
6. Cover carbon brush
7. On/off switch
8. Blocking switch
9. Dust collection opening
10. Dust bag
11. Drive belt cover
12. Adjusting knob aligning sanding belt
13. Sanding belt
Voltage | 230 V~
Frequency | 50 Hz
Power input | 950 W
No load sander paper speed | 370m/min
Sanding belt size | 75 x 533 mm
Sanding pad size | 75 x 150 mm
Weight | 3.7 kg
Lpa (Sound pressure) | 94 dB(A)
Lwa (Sound power level) | 170 dB(A)
Vibration value | 2.4 m/s
2
Powercraft 3
Spare parts list PBS-950
Powercraft nr. Description Position
409232 Carbon brush (set) 26
409233 Adjusting knob (set) 28 till 30
409234 Rear wheel 35
409235 Bottom plate 48
409236 Belt 49
409237 Switch 61
409238 Dustbag -
