7
ENGLISH
INSTRUCTION MANUAL
Introduction
To get the most out of your new multi grinder,
please read these instructions and the attached safety
instructions before use. Please also save the instruc-
tions in case you need to refer to them at
a later date.
Main components
1. On/off switch
2. Speed selector
3. Shaft lock
4. Chuck
5. Chuck key
Special safety precautions
• Never activate the shaft lock when the grinder is
switched on.
• Do not subject to large loads at slow speeds.
• If the machine locks up, switch off immediately.
• Use accessories with the same shaft diameter
as the chuck.
• Do not exceed the maximum permitted rotation
speeds (RPM) for the various attachments.
Changing attachements
1. Disconnect from the mains.
2. Press and hold the shaft lock.
3. Loosen chuck using chuck key.
4. Insert the shaft of the attachment into
the chuck.
5. Tighten chuck using chuck key.
6. Connect to the mains.
Start, stop and speed control
Switch on and off using the ON/OFF switch.
You can control the rotation speed of between 10,000
to 30,000 RPM by turning the speed selector.
If vibration becomes excessive, try increasing the
RPM.
Maintenance
Wipe using a well-wrung cloth after use, and always
keep the surface and ventilation holes free of dirt.
Never use corrosive or abrasive detergents, as they
may affect the plastic parts.
Technical data
Voltage/frequency: 230 V ~ 50 Hz
Power rating: 135 W
Speed: 10,000 -30,000 RPM
Chuck diameter: 3.2 mm
Weight: approx. 600 grams
Sound level (LPA): 82.4 dB(A)
Sound capacity (LWA): 95.4 dB(A)
Vibration: 2.239 m/s2
