TECHNICAL SPECIFICATION / TECHNISCHE SPECIFICATIE / TECHNISCHE
DATEN / ESPECIFICACIONES TÉCNICAS / SPÉCIFICATIONS TECHNIQUES /
SPECYFIKACJA TECHNICZNA
Output power MAX : 100W
Output power RMS : 50W
Diameter tweeter : 1/2”
Diameter woofer : 5.25”
Tweeter type : Mylar
Magnet type : Ferrite
Impedance : 8Ohm
Frequency response : 70Hz - 16KHz
SPL @ 1W/1m : 86dB
Power supply : 100-240VAC 50/60Hz
Power consumption : 0.52 - 0.29A
Dimensions per speaker (L x W x H) : 200 x 170 x 250mm
Weight (kg) : 4,35
The specifications are typical. The actual values can slightly change from one unit to the other. Specifications can
be changed without prior notice.
The products referred to in this manual conform to the European Community Directives to which they are subject:
• Low Voltage (LVD) 2014/35/EU
• Electromagnetic Compatibility (EMC) 2014/30/EU
• Radio Equipment Directive (RED) 2014/53/EU
• Restriction of Hazardous Substances (RoHS) 2011/65/EU
