resonances, the sound should be reflected in different ways. A shelf with many books of
different sizes can do the trick. However, you can also buy so-called diffusers, specially
designed for the diffusion of sound waves.
If you think an excellent low-frequency performance is important, we recommend you to
leave enough space between the speakers and the back wall.
The removement of unnecessary high-frequency killers, e.g. by drawing the curtains,
can result in a more dynamic sound. We recommend that you use dampening material
sparingly and only in the case of real disturbances.
Keep the curtains open!
Make sure, while setting up the speakers, that the distance between the speakers can
be 1.2 times as much as the distance between the speakers and the listener. All of this,
results in a large sound stage, and every single instrument is better separated from the
others in terms of room space.
Changing fuses:
Under normal operation the fuses should not blow. Usually a blown fuse is caused by
overload or faulty conditions. Do not change the fuse by yourself; this should be done by
an authorized technician. If the fuse blows immediately after turning on the power, then
the speaker should be returned to a dealer for repair.
Specifications: Galax 5 Galax 6 Galax 8
Galax 10S
Type: 178.940 178.943 178.946
178.950
Frequency Range:
53Hz - 20kHz 55Hz - 20kHz 40Hz - 20kHz 35Hz - 165Hz
Rated output power: 100W Music 150W Music 180W Music 350W Music
Rated output
power:RMS 15W/35W 15W/50W 15W/75W 175W
Crossover frequency:
3kHz 2.6kHz 2.4kHz -
THD
0.05 / 0.02 0.05 / 0.02 0.05 / 0.02
S/N
>90dB >90dB >90dB >90dB
HF driver:
RIBBON RIBBON RIBBON -
Power requirements:
220-240Vac /
50Hz
220-240Vac /
50Hz
220-240Vac /
50Hz
220-240Vac /
50Hz
Dimensions (W x H x
D):
165 x 200 x
265mm
200 x 250 x
315mm
250 x 305 x
390mm
382 x 322 x
398mm
