Specifications
Specification PDA-B1500 PDA-B2000
Ref. No. 171.193 171.194
4 Ohm Stereo Power (RMS) 2x 750W 2x 1000W
8 Ohm Stereo Power (RMS) 2x 500W 2x 600W
2 Ohm Stereo Power (RMS) 2x 1000W 2x 1500W
8 Ohm Bridge Power (RMS) 1500W 2000W
4 Ohm Bridge Power (RMS) 2000W 2800W
Frequency Response 10Hz – 50kHz (±1.5dB)
Input Sensitivity 770mV
Maximum Input Level 21dBv/9v
Input Impedance 20kOhm
Signal/Noise Ratio A-weighted RMS >95dB
Crosstalk @
Rated Output Power 8 Ohm / 1kHz
>105dB
Damping Factor @ 8 Ohm / 1kHz >500
Slew Rate Internal 60V/µS
Protection
Short Circuit, Current Limited, DC Fault, AC Line Fuse,
Thermal Cut Off, Power Up/Down, Slow Start
Power Supply 220-240Vac, 50Hz
Dimensions (bxhxd) 482 x 380 x 88mm (19” x 2U)
Weight 23kg 24kg
Note: Specifications and design are subject to change without notice for purpose of improvement.
Electric products must not be put into household waste. Please bring them to a recycling centre. Ask your
local authorities or your dealer about the way to proceed.
WARRANTY CONDITIONS
The date the product leaves the importer is considered to be the date the warranty begins. The law obliges the
retailer to offer a two year quarantee to the enduser.
Only companies approved by Tronios are allowed to work on the equipment.
During warranty period (defective) equipment must be returned to the dealer by pre-paid mail in the original box.
Potentiometers have a limited lifetime and are not covered by the manufacturer for more than normal use. For all
service enquiries,refer to your local distributor,as he is best able to help you.
