Power Dynamics PDM-C405A User Manual

21
TECHNICAL SPECIFICATION / TECHNISCHE SPECIFICATIE / TECHNISCHE
DATEN / ESPECIFICACIONES TÉCNICAS / SPÉCIFICATIONS TECHNIQUES /
SPECYFIKACJA TECHNICZNA
PDM-C405A
PDM-C805A
Ref.nr:
171.157
171.159
Rated voltage:
110-240V AC 50-60Hz
Rated power:
150 Watt
Delay time:
140-342ms
Graphic equalizer:
3-bands
Bass, treble, mid
5-bands
100Hz, 500Hz, 1Khz, 2.5Khz,
10Khz +/- 12dB
Frequency response:
20HZ-20Khz +1db/-3db
Input impedance:
Microphone XLR 2K Ohm Balanced
Jack 6.3mm 1K Ohm Unbalanced
Line 10K Ohm
Tape In 47K Ohm
Channels:
4
8
Dimensions:
475x230x140mm
475x230x220mm
Weight:
6.5Kg
7,45Kg
The specifications are typical. The actual values can slightly change from one unit to the other. Specifications can be changed
without prior notice.

Power Dynamics PDM-C405A Specifications

General

Brand	Power Dynamics
Model	PDM-C405A
Category	Music Mixer
Language	English
