III. BATTERY CONNECTION
Use 12V and more than 18AH battery, connect its positive lead to start
relay terminal while connect its negative lead to engine mounting screw,
base screw or other grounding point with the engine.(See the following
picture)
Check the battery's connecting point; make sure that it is tight and not
rusted. If rusted, clean and connect.
1) The battery may give off explosive gas, keep sparks, ames and
cigarettes away. Charge or use it indoors with good ventilation.
2) The battery contains sulphuric acid (electrolyte). If contact with
skin or eyes may cause severe burns. If electrolyte gets in your
skin, ush with water; if gets in your eyes, ush with water for at
least 15 minutes and call a physician at once.
3) Electrolyte is poisonous. If swallowed, drink large quantities of
BATTERY CONNECTION
CATHODE WIRE(-)
START RELAY
ANODE WIRE(+)
10
Use a 12V
Start Relay
cigarettes away.
a physician.
