Assembly Instructions
From below, slide lower spray gun holder (B) tabs into
slots on bottom left side of power washer unit (D).
Slide upper spray gun holder (A) tab into slot on left side
of power washer unit (D).
D
B
5
Hold back the collar at one end of the hose (G). Push
firmly to connect hose fitting to the water outlet tube on
the front of the power washer unit (D). Twist the collar
clockwise to secure. Confirm hose is locked into the
water outlet by slightly pulling on the hose.
Note: DO NOT use pliers or locking pliers to tighten.a
6
G
D
4
A
D
To Next Page
