Assembly Instructions
8
Hold back the collar at the other end of the hose (G).
Push firmly to connect hose fitting to spray gun (H). Twist
collar clockwise to secure. Confirm hose is locked into
spray gun by slightly pulling on them.
3
2
7
1
H
G
G
H
H
Lock
Unlock
I
9
I
1
3
8
2
H
G
G
To remove the hose, twist collar counter clockwise then
pull back to release the hose (G) connection from the spray
gun (H).
To lock the trigger of the spray gun (H), aim the gun
away from you and pull up on the safety lock (I). After
doing so, squeeze or pull the trigger to make sure it is
locked and will not move. ALWAYS keep spray gun (H)
locked when not in use.
