7.4 Backing Pad accessory Installation (Fig. 3)
The sanding plate (iron-shaped / round / rectangular sanding base) is equipped with a hook
and loop rubber backing pad. This uses hook and loop backed accessories, which firmly grip
the backing pad when applied with moderate pressure.
To change, merely peel off the old accessory, remove dust from the backing pad if necessary
and press the new accessory in place. Be sure to align the sanding sheet holes with the holes
in the backing pad as best you can to allow the dust extraction system to function effectively.
After considerable use the backing pad surface will become worn, and must be replaced when
it no longer offers a firm grip. If the backing pad facing is wearing prematurely, decrease the
amount of pressure applied during the operation of the tool. Damage to the pad is not covered
the warranty.
7.5 Using the dust collection box (4) (Fig. 4)
The dust extraction system extracts sanding dust from the work piece through the holes in
the backing pad. The dust is then transferred through the dust extraction port (5) on the
rear of the sander housing.
To install: pull and slide dust collection box (4) into the dust extraction port (5), make sure
the latches on the right and left of the dust collection box (4) into place and it is secure
before beginning operation.)
To remove: When removing the dust collection box (4), follow the above procedure in
reverse order.
If the dust collection box (4) is full, you can remove it from this tool and open the cover of box,
empty dust, wood bust, etc. in the body, finally clean the dust collection box.
To remove: Hold the top cover (A) with one hand and the lower cover with the other.
Disconnect the top cover form the lower cover. (B)
To install: When assembling the dust collection box, follow the above procedure in reverse
order.
8 TECHNICAL DATA
Sanding surface, rectangular
Sanding surface, iro,-shaped
