Power smart DB2194PR User Manual

25
Item
Stock #
Description
Qty
Item
Stock #
Description
Qty
E01-1
11310-Z3C0110-00A0
CRANKCASE
SUBASSEMBLY.
1
E04-3
90408-Z030210-0000
WASHER， FLAT
1
E01-2
90682-Z240110-0000
SEAL, OIL
1
E04-4
14200-Z2P0110-00A0
CAMSHAFT ASSY.
1
E01-3
90682-Z030210-0000
SEAL, OIL
1
E04-5
13122-Z240110-00A0
CLIP, PISTON PIN
2
E01-4
90103-0410-51
SCREW
1
E04-6
13121-Z240110-00A0
PIN, PISTON
1
E01-5
11321-Z2P0110-0000
PIECE, BREATH
1
E04-7
13010-Z2P0110-00A0
ROD, CONNECTING
1
E01-6
11337-Z2P0110-0000
LIMIT BOARD
1
E04-8
13111-Z3C0110-00A0
PISTON
1
E01-7
90007-0512-A1
BOLT
1
E04-9
13200-Z870110-00A0
RING ASSY, PISTON
1
E01-8
11333-Z2P0110-0000
PLATE, BREATH GROOVE
COVER
1
E05-1
90107-0516-01
SCREW
3
E01-9
16061-Z2P0110-00A0
ARM, GOVERNOR
1
E05-2
80001-Z2P0210-RC00
HOUSING, ENGINE
1
E01-10
90501-Z010110-0000
PIN
1
E05-3
28200-Z2P0310-Q200
STARTER ASSY,
RECOIL
1
E01-11
90412-Z870210-0000
WASHER， FLAT
1
E05-4
90007-0516-A1
BOLT
4
E01-12
16062-Z2P0110-0000
ROD, GOVERNEOR
1
E06-1
90204-Z010210-0100
BOLT
1
E01-13
16072-Z010110-0000
BOLT, GOVERNOR
SUPPORT
1
E06-2
17002-Z2P0110-00A0
GASKET, INLET
1
E01-14
90305-0600-31
NUT
1
E06-3
16003-Z2P0110-00A0
PLATE, CARBURETOR
INSULATOR
1
E01-15
16070-Z2P0110-0000
SUPPORT SUBASSEMBLY,
GOVERNOR
1
E06-4
16004-Z2P0110-00A0
GASKET, INSULATOR
PLATE
1
E01-16
16063-Z2P0110-0000
SPRING, GOVERNOR
1
E06-5
16100-Z3C0210-00A0
CARBURETOR ASSY.
1
E01-17
19308-Z2P0110-0000
SHIELD, CRANKCASE
SIDE
1
E06-6
90685-1000-01
CLAMP
1
E01-18
90007-0512-A1
BOLT
1
E06-7
90686-Z2P0110-0000
TUBE, FUEL
1
E01-19
11340-Z2P0110-0000
Return oil block assembly
1
E06-8
90685-0700-01
CLAMP
2
E01-20
16561-Z2P0110-0000
PLATE SUBASSEMBLY,
THROTTLE CONTROL
BOTTOM
1
E06-9
16211-Z2P0110-0000
TUBE, STARTING
RICHED VALVE
1
E01-21
90007-0512-A1
BOLT
1
E06-10
16212-Z2P0110-0000
SEAT, STARTING
RICHED VALVE
1
E01-22
15010-Z2P0310-Q200
DIPSTICK, OIL
1
E06-11
16213-Z2P0110-0000
VALVE BODY,
STARTING RICHED
1
E02-1
11411-Z2P0110-00A0
COVER, CRANKCASE
1
E10-1
13501-Z010110-00A0
NUT, FLYWHEEL
1
E02-2
90682-Z030320-0000
SEAL, OIL
1
E10-2
19352-Z2P0110-00A0
IMPELLER
1
E02-3
90001-0630-01
BOLT
7
E10-3
28020-Z2P0110-0000
SEAT, STARTER CUP
1
E02-4
16400-Z2P0111-00A0
GEAR ASSY, GOVERNOR
1
E10-4
13510-Z2P0110-00A0
FLYWHEEL
SUBASSEMBLY
1
E02-5
16013-Z030120-0000
PLATE, GOVERNOR
SPINDLE COMPRESSION
1
E10-5
30029-Z2P0110-0000
LUG， SHROUD
1
E02-6
90001-0616-01
BOLT
1
E10-6
90007-0516-A1
BOLT
1
E02-7
90502-0812-00
PIN
2
E10-7
45200-Z2P0110-JS00
BRAKE ASSY.
1
E03-1
14081-Z2P0110-00A0
TAPPET, VALVE
2
E10-8
90007-0520-A1
BOLT
3
E03-2
14071-Z2P0110-00A0
LIFTER, VALVE
2
E10-9
30400-Z2P0110-0000
COIL, IGNITION
1
E03-3
12131-Z3C0110-00A0
GASKET, CYLINDER
HEAD
1
F01-1
17001-Z2P0110-00A0
GASKET, AIR
CLEANER
1
E03-4
12140-Z3C0110-00A0
HEAD SUBASSEMBLY,
CYLINDER
1
F01-2
17100-Z2P0110-0000
CLEANER, AIR
1
E03-5
90001-0850-01
BOLT
4
F01-3
90305-0600-31
NUT
2
E03-6
30010-Z120110-00A0
PLUG, SPARK
1
F01-4
17004-Z2P0110-0000
TUBE, BREATHER
1
E03-7
12101-Z810210-00A0
GUIDE, SEAL
1
F02-1
90107-0413-03
BOLT
3
E03-8
12110-Z3C0110-00A0
VALVES SET
2
F02-2
18130-Z2P0210-0000
COVER, MUFFLER
OUTER
1
E03-9
12103-Z030110-0000
SPRING, VALVE
2
F02-3
90001-0616-01
BOLT
2
E03-10
12112-Z010110-00A0
SEAT, VALVE SPRING
2
F02-4
18100-Z2P0210-0000
MUFFLER ASSY.
1
E03-11
14310-Z2P0110-00A0
ROCKER SUBASSEMBLY,
VALVE
2
F02-5
18020-Z2P0110-00A0
PLATE, MUFFLER
INSULATOR
1
E03-12
14330-Z2P0110-00A0
SHAFT, VALVE ROCKER
1
F03-1
16600-Z2P0110-Q2A9
TANK ASSY, FUEL
1
E03-13
12411-Z2P0110-0000
COVER, CYLINDER HEAD
1
F03-2
16744-Z620120-0000
TANK CAP CHAIN
1
E03-14
90007-0512-A1
BOLT
4
F03-3
16730-Z620210-LKD0
COVER, FUEL TANK
1
E04-1
13300-Z3C0910-00A0
CRANKSHAFT ASSY.
1
F03-4
16652-Z030110-00A0
STRAINER，FUEL
1
E04-2
14014-Z2P0210-00A0
GEAR, TIMING DRIVE
1
F03-5
90685-1000-01
CLAMP
1
