Power smart DB2194SH User Manual

22
Item
Stock
#
Description
Qty
Item
Stock
#
Description
Qty
1
9999960902
Engine 1 50 203100004
Tensioning pulley
assembly
1
2 303090094 Gear box seat 1 51 303160195A Small tensioning sleeve 1
3 303100100 Bearing 1 52 303181406 Small tensioning plate 1
4 303160961 Left hand bevel gear 1 53 303160192B
Small tensioning plate
spacer
1
5 303020240 Bolt 6 54 303020154 Bolt M8*40 1
6 303042005 Flat washer 4 55 303130383 Tension spring 1
7 303160962 Right bevel gear 1 56 203050520 Walking support pad 1
8 303071551 Paper pad 1 57 203050397A 8 inch Right wheel 1
9 303090095 Gear box cover 1 58 303050007 Shaft ring 4
10 303020142 Bolt M8*10 1 59 303100065 Stamping bearings 6
11 303160791 Bolt M8*60 4 60 303160470A Advance gear Right 1
12 303020649 Bolt M8×20 4 61 303123017A Cylindrical pin 2
13 303020506 Bolt M8*12mm 2 62 203010851 Dust cover 2
14
303110045
Flat
key
1
63
303181412
Rear
self
drive
axle
1
15 303100045 Deep groove ball bearing 2 64 303071059
Rear adjustment spring
leaf
1
16 303100101 Long axis 1 65 303020339 Bolt M6*14 4
17 303050066 Shaft ring 1 66 303160471A Drive gear Left 1
18 303160963 Two-groove belt pulley 1 67 203050398A 8 inch Left wheel 1
19 303110047 Flat key 1 68 203021336 Rear axle sleeve 2
20 203050382A Side discharge chute 1 69 302120079 Grass collector 1
21 203050381B Side discharge deflector 1 70 303240703 Drive assembly 1
22 303130379 Torsional spring 1 71 302040093 V-belt 1
23 303090066A Torsional spring pin 1 72 303080491A Collector holder 1
24 303160833 Side discharge bracket 1 73 302080050B Rubber sheet 1
25 303020468 Screw M6x10mm 2 74 303010095 Screw ST4.2*14 2
26 303050067 Retaining ring 1 75 203050389 Rear block cover 1
27 303100102 Short axis 1 76 303130381
Rear cover torsional
spring left
1
28
303100103
Deep
groove
ball
bearing
2
77
203050390B
Rear
cover
1
29 303071552 Bearing seat 1 78 303130380
Rear cover torsional
Spring
right
1
30 303020672 Bolt M8*10 1 79 303030140A Rear seat square nut 2
31 303181409 Steel deck 1 80 203050400C Rear seat 1
32 303010378 Self-tapping screw 16 81 303121005 Cotter pin 2
33 203050399C Front cover 1 82 302060025 Rubber stopper 1
34 303071058
Front adjustment spring
leaf
assembly
1 83 303160807 Axis pin 2
35 303030032 Nylon locknut M6 4 84 303020558 Screw M6*35 2
36 303030077 Flange nylon nut M8 5 85 203050519 Wire clip 1
37 203050648 7 inch Right wheel 1 86 303081331 Lower handle L 1
38 303181410 Front axle welding 1 87 303081333 Lower handle R 1
39 303071420 Axle keeper 2 88 303020057 T bolt 2
40 303010216 Self-tapping screw 8 89 303030026 Nut M8 2
41
203050649
7
inch
Left
wheel
1
90
203020336A
Knob
2
42
303020626
Blade
Bolt
1
91
303010374
Screw
ST6.3*35mm
2
43 303043023A Butterfly washer 1 92 203050661
Engine pull rope fixing
seat
1
44 303071037 21 inch Blade 1 93 303030025 Cap nut 1
45 303181407 Blade connector 1 94 303200148 Cable 1
46 203052967 Belt cover 1 95 303020308 Bolt M6*30 1
47 303110049 Square Key 1 96 303080502 Drive control bar 1
48 303060169 Multi wedge pulley 1 97 303081329 Upper handle 1
49 302040092 Multi wedge belt 1 98 303080509 Cutting control bar 1
