27
Item Stock # Description Qty Item Stock # Description Qty
E01-1
11310-Z3E0111-00A1 CRANKCASE SUBASSEMBLY. 1
E04-8
13111-Z3E0110-00A0 PISTON 1
E01-2
90682-Z240110-0000 SEAL, OIL 1
E04-9
13200-Z3E0110-00A0 RING ASSY, PISTON 1
E01-3
90682-Z030210-0000 SEAL, OIL 1 E05-1 90107-0516-01 SCREW 3
E01-4
90103-0410-51 SCREW 1 E05-2 80001-Z2P0210-Q200 HOUSING, ENGINE 1
E01-5
11321-Z2P0110-0000 PIECE, BREATH 1 E05-3 28200-Z2P0310-Q2A0 STARTER ASSY, RECOIL 1
E01-6
11337-Z2P0110-0000 1 E05-4 90007-0520-A1 BOLT 4
E01-7
90007-0512-A1 BOLT 1
E06-1
90204-Z010210-0100 BOLT
1
E01-8
11333-Z2P0110-0000
PLATE, BREATH GROOVE
COVER
1
E06-2
17002-Z2P0110-00A0 GASKET, INLET
1
E01-9
16061-Z2P0110-00A0 ARM, GOVERNOR 1
E06-3
16003-Z2P0110-00A0 PLATE, CARBURETOR INSULATOR
1
E01-10
90501-Z010110-0000 PIN 1
E06-4
16004-Z2P0110-00A0 GASKET, INSULATOR PLATE
1
E01-11
90412-Z870210-0000
WASHER， FLAT
1
E06-5
16100-Z3E0110-00A0 CARBURETOR ASSY.
1
E01-12
16062-Z2P0110-0000 ROD, GOVERNEOR 1
E06-6
90685-Z030410-0000 CLAMP
1
E01-13
16072-Z010110-0000 BOLT, GOVERNOR SUPPORT 1
E06-7
90686-Z2P0111-00M0 TUBE, FUEL 1
E01-14
90305-0600-31 NUT 1
E06-8
90685-0700-01 CLAMP
2
E01-15
16070-Z2P0110-0000
SUPPORT SUBASSEMBLY,
GOVERNOR 1
E06-9
16211-Z2P0110-0000 TUBE, STARTING RICHED VALVE
1
E01-16
16063-Z2P0110-0000 SPRING, GOVERNOR 1
E06-10
16212-Z2P0110-00A0 SEAT, STARTING RICHED VALVE
1
E01-17
19308-Z2P0110-0000 SHIELD, CRANKCASE SIDE 1
E06-11
16213-Z2P0110-00A0 VALVE BODY, STARTING RICHED
1
E01-18
90007-0512-A1 BOLT 1
E10-1
13501-Z010110-00A0 NUT, FLYWHEEL 1
E01-19
11340-Z2P0110-0000 1
E10-2
19352-Z2P0110-00A0 IMPELLER 1
E01-20
16561-Z2P0110-0000
PLATE SUBASSEMBLY,
THROTTLE CONTROL
BOTTOM
1
E10-3
28020-Z2P0110-0000 SEAT, STARTER CUP 1
E01-21
90007-0512-A1 BOLT 1
E10-4
13510-Z2P0111-0000 FLYWHEEL SUBASSEMBLY 1
E01-22
15010-Z2P0310-Q200 DIPSTICK, OIL 1
E10-5
30029-Z2P0110-0000
LUG， SHROUD
1
E02-1
11411-Z2P0111-00A0 COVER, CRANKCASE 1
E10-6
90007-0514-A1 BOLT 1
E02-2
90682-Z030320-0000 SEAL, OIL 1
E10-7
45200-Z2P0310-0000 BRAKE ASSY. 1
E02-3
90001-0630-01 BOLT 7
E10-8
90007-0520-A1 BOLT 3
E02-4
16400-Z2P0111-00A0 GEAR ASSY, GOVERNOR 1
E10-9
30400-Z2P0110-0000 COIL, IGNITION 1
E02-6
90001-0616-01 BOLT 1
E10-1
13501-Z010110-00A0 NUT, FLYWHEEL 1
E02-7
90502-0812-00 PIN 2
E10-2
19352-Z2P0110-00A0 IMPELLER 1
E03-1
14081-Z2P0110-00A0 TAPPET, VALVE 2
E10-3
28020-Z2P0110-0000 SEAT, STARTER CUP 1
E03-2
14071-Z2P0110-00A0 LIFTER, VALVE 2
E10-4
13510-Z2P0111-0000 FLYWHEEL SUBASSEMBLY 1
E03-3
12131-Z3E0110-00A0 GASKET, CYLINDER HEAD 1
E10-5
30029-Z2P0110-0000
LUG， SHROUD
1
E03-4
12140-Z3E0210-00A0
HEAD SUBASSEMBLY,
CYLINDER
1
E10-6
90007-0514-A1 BOLT 1
E03-5
90001-0850-01 BOLT 4
E10-7
45200-Z2P0310-0000 BRAKE ASSY. 1
E03-6
30010-Z120110-00A0 PLUG, SPARK 1
E10-8
90007-0520-A1 BOLT 3
E03-7
12101-Z810210-00A0 GUIDE, SEAL 1
E10-9
30400-Z2P0110-0000 COIL, IGNITION 1
E03-8
12110-Z2P0110-00A0 VALVES SET 2
F01-1
17001-Z2P0110-00A0 GASKET, AIR CLEANER 1
E03-9
12103-Z030110-0000 SPRING, VALVE 2
F01-2
17100-Z2P0110-0000 CLEANER, AIR 1
E03-10
12112-Z010110-00A0 SEAT, VALVE SPRING 2
F01-3
90305-0600-31 NUT 2
E03-11
14310-Z2P0110-00A0
ROCKER SUBASSEMBLY,
VALVE 2
F01-4
17004-Z2P0110-0000 TUBE, BREATHER 1
E03-12
14330-Z2P0110-00A0 SHAFT, VALVE ROCKER 1
F02-1
90107-0413-03 BOLT 3
E03-13
12411-Z2P0110-0000 COVER, CYLINDER HEAD 1
F02-2
18130-Z2P0210-0000 COVER, MUFFLER OUTER 1
E03-14
90007-0512-A1 BOLT 4
F02-3
90001-0616-01 BOLT 2
E04-1
13300-Z2P1410-00A0 CRANKSHAFT ASSY. 1
F02-4
18100-Z2P0210-0000 MUFFLER ASSY. 1
E04-2
14014-Z2P0210-00A0 GEAR, TIMING DRIVE 1
F02-5
18020-Z2P0111-00A0 PLATE, MUFFLER INSULATOR 1
E04-3
90408-Z030210-0000
WASHER， FLAT
1
F03-1
16600-Z2P0110-Q2M9 TANK ASSY, FUEL
1
E04-4
14200-Z2P0111-00A0 CAMSHAFT ASSY. 1
F03-2
16744-Z620120-0000
CHAIN PROOF OFF， FUEL TANK
COVER
1
E04-5
13122-Z240110-00A0 CLIP, PISTON PIN 2
F03-3
16730-Z620210-LKD0 COVER, FUEL TANK 1
E04-6
13121-Z240110-00A0 PIN, PISTON 1
F03-4
16652-Z030110-00A0
STRAINER，FUEL
1
E04-7
13010-Z2P0110-00A0 ROD, CONNECTING 1
F03-5
90685-Z030410-0000 CLAMP 1
