9
ASSEMBLY INSTRUCTION
WARNING:
Do not use this product if any parts on the packing list are already assembled to your product
when you unpack it. Parts on this list are not assembled to the product by the manufacturer
and require customer installation. Use of a product that may have been improperly assembled
could result in serious personal injury.
WARNING:
If any parts are damaged or missing do not operate this product until the parts are replaced.
Use of this product with damaged or missing parts could result in serious personal injury.
WARNING:
Do not attempt to modify this product or create accessories not recommended for use with
this product. Any such alteration or modification is misuse and could result in a hazardous
condition leading to possible serious personal injury.
WARNING:
Do not connect to power supply until assembly is complete. Failure to comply could result in
accidental starting and possible serious personal injury.
INSERTING AND REMOVING SAW BLADE
WARNING: Before any work on the power tool, remove the battery.
When mounting the saw blade, wear protective gloves. Danger of injury when touching the
saw blade. Use only saw blades suitable for the material being worked.
To install the saw blade
1. Turn the locking sleeve approx. 90°in the direction of the
and hold (see fig.2).
2. Push the saw blade into the saw blade holder.
3. Release the locking sleeve again.
4. Check the tight seating of the saw blade.
For certain work, the saw blade can also be turned through 180
(with the teeth pointed upwards) and re-inserted again.
To remove the saw blade
1. Turn the locking sleeve approx.90°in the direction of the arrow and hold.
2. Remove the saw blade.
Fig.2
