12
lower handle using cable clip.
4. Insert the recoil starter handle cable into the hook provided on the upper handle. You must engage the start/stop
control to release the recoil starter handle.
SIDE DISCHARGE CHUTE
To convert mower for side discharge, the grass catcher has been removed and that the rear discharge door is
closed.
1. Lift the spring-loaded discharge cover located on the side of the mower.
2. Slide two hooks of the side discharge chute under the hinge pin and lower the spring on the side discharge
cover.
Caution: Do not attempt to remove the permanently mounted spring loaded side discharge cover at any time.
GRASS CATCHER
Attach grass catcher
1. Lift mower rear discharge door.
2. Place grass catcher into the slots in the handle brackets.
3. Release the rear discharge door so that it rests on the grass catcher.
