Power smart PSM2521PH User Manual

21
7 303160962 Right bevel gear 1 51 203100004
Tensioning pulley
assembly
1
8 303071551 Paper pad 1 52 303160195A Small tensioning sleeve 1
9 303090095 Gear box cover 1 53 303181406 Small tensioning plate 1
10 303020142 Bolt M8*10 1 54 303160192B
Small tensioning plate
spacer
1
11 303160791 Bolt M8*60 4 55 303020154 Bolt M8*40 1
12 303020649 Bolt M8×20 4 56 303130383 Tension spring 1
13 303020506 Bolt M8*12mm 2 57 303100065 Stamping bearings 4
14 303110045 Flat key 1 58 203050492A 8 inch Right wheel 1
15 303100045 Deep groove ball bearing 2 59 303181417 Rear axle welded 1
16 303100101 Long axis 1 60 303071059
Rear adjustment spring
leaf
1
17
303050066
Shaft
ring
1
61
203050493A
8
inch
Left
wheel
1
18
303160963
Two-groove
belt
pulley
1
62
302120079
Grass
collector
1
19 303110047 Flat key 1 63 303080491A Collector holder 1
20 203050382A Side discharge chute 1 64 302080050B Rubber sheet 1
21 203050381B Side discharge deflector 1 65 303010095 Screw ST4.2*14 2
22 303130379 Torsional spring 1 66 203050389 Rear block cover 1
23 303090066A Torsional spring pin 1 67 303130381
Rear cover torsional
spring
left
1
24 303160833 Side discharge bracket 1 68 203050390B Rear cover 1
25 303020468 Screw M6x10mm 2 69 303130380
Rear cover torsional
Spring
right
1
26 303050067 Retaining ring 1 70 303030140A Rear seat square nut 2
27 303100102 Short axis 1 71 203050400C Rear seat 1
28 303100103 Deep groove ball bearing 2 72 303121005 Cotter pin 2
29 303071552 Bearing seat 1 73 303160807 Axis pin 2
30
303020672
Bolt
M8*10
1
74
303020558
Screw
M6*35
2
31
303181414
Steel
deck
1
75
203050519
Wire
clip
1
32
303010378
Self-tapping
screw
15
76
303081331
Lower
handle
L
1
33 203050399C Front cover 1 77 303081333 Lower handle R 1
34 303020339 Bolt M6*14mm 4 78 303020057 T bolt 2
35 303071058
Front adjustment spring
leaf
assembly
1 79 303030026 Nut M8 2
36 303030032 Nylon locknut M6 4 80 203020336A Knob 2
37 303030077 Flange nylon nut M8 5 81 303010374 Screw ST6.3*35mm 1
38 203050430 7 inch Right wheel 1 82 203050661
Engine pull rope fixing
seat
1
39 303181410 Front axle welding 1 83 303030025 Cap nut 1
40 303071420 Axle keeper 4 84 303200150 Cable 1
41 303010216 Self-tapping screw 8 85 303020308 Bolt M6*30 1
42 203050431 7 inch Left wheel 1 86 303081329 Upper handle 1
43 303020626 Blade Bolt 1 87 303080490 Cutting control bar 1
44 303043023A Butterfly washer 1 88 302020010 Sponge cover 1
ENGINE EXPLODE VIEW AND PART LIST
