3
We reserve the right to change the specification without notice.
USB
Portable power supply
1200 A
6.3 L 3.5 L
For all 12 V vehicles
Petrol Diesel
** PS-OBDII
* PS-7601-0004
USING THE USB OUTPUT: (5 V, 2.1 A OR 1.0 A)
The Power-Start can also be used as a Powerbank source to recharge telephone’s and or tablets (or any other similar 5 V devices).Turn on the PS-775LI. If battery capacity is below 20%, please recharge
the unit (continue with the above steps: Charging the Power-Start). If battery capacity is above 40%, connect the 5 V device to the PS-775LI. If the device is using over 120 Watt the LCD display will
illuminate and tell “WARNING OVER LOADING DISCONNECT NOW”, disconnect the 5 V device. If the device is under the 120 Watt, you can use it, untill the internal battery runs below 10.5 V. The Power-
Start will shut off and stop the output. Disconnect the 5 V device. Then continue with the above steps: Charging the Power-Start.
USING THE LIGHT FROM THE JUMP STARTER
It is not needed to switch on the Power-Start by pushing the “Power” button. You can just push the “On/off” button of the light, the LCD display will illuminate and show the state of charge (SOC). The
LED will light up within 3 seconds (to full power). If you leave it on, It will go out when the internal battery runs below 10.5 V. The Power-Start will shut off and stop the output. Then continue with the
above steps: Charging the Power-Start (If you don’t need the light anymore, you can easily switch it off at any time, by pushing the “On/off” button once more).
MAINTENANCE
The unit case must not be opened as there are no user serviceable parts inside and this will invalidate the warranty.
VOLTAGE “SPIKE” PROTECTION
The Power-Start has a spike protection system. This protection is in operation as long as the clamps are connected to the vehicle, even when the unit is switched off. NEVER remove one of the clamps
before the Power-Start is switched off.
DISPOSAL
The battery inside the Power-Start is a Li-Ion type, LiFePO4. It must be removed and recycled or disposed of properly at the end of its useful life.
TECHNICAL SPECIFICATIONS
Power source 12 V, 8 Ah
Cranking amps 775 A
Peak amps 1200 A
Polarity alarm Acoustic and in text on LCD
Cable size 16 mm²
Clamps Fully insulated heavy duty 1000 A bended
Housing Strong ABS case (Acrylonitrile Butadiene Styrene)
LxDxH mm 215x125x260
Weight 3.3 kg
Mains charger 2 A, 230 V AC - 14.8 V DC
Car charger
12 V DC (short and quick charge only)
Ean code 8717775519607
Working temperature -20 ~ 50°C
Hydrocarbon and UV resistant
Error conditions: Solution:
Jumpstart ready Ready for use
Warning clamps are reversed Disconnect the clamps and reconnect correctly
Warning high voltage Vehicle battery is over 15 V, disconnect the clamps
Cranking time exceeded Cranking time maximum 8 seconds, then re-attempt
Excessive current discharge Cranking with too high current
Example: 12 V over 600 A for 2 Seconds
Low battery Recharge the battery
Battery temperature too high Battery needs to cool down, wait for battery to cool down
Mosfet temperature too high Mosfet needs to cool down, wait for Mosfet to cool down
Short circuit Remove the short circuit
Remove clamps Remove the clamps from the vehicle
USB or 12 V overload Device is taking more than 120 W, disconnect the device
Low voltage, 10.5V Recharge the battery
Temperature below 0°C Turn on consumers to heat up internal battery
