Page 33 of 41
9. Screw the hose barb on to the filter and tighten. DO NOT over tighten.
10. Screw the filter and hose barb assembly on to the inlet side of the pump and tighten. DO NOT over
tighten.
11. Inspect fuel hose and clamp. Replace if necessary.
12. Reattach the fuel hose and clamp to the hose barb.
13. Bolt the fuel pump and filter assembly back into position.
14. Bleed the air from the fuel system.
15. Clean up any spilled fuel.
16. Dispose of the old filter according to local regulations
