What to do if the Power Walker VFI 1000RM is overloaded?
If the Power Walker UPS is overloaded, it means that you need to remove some of the devices connected to the UPS output. If the devices are fed directly by the electrical network via the Bypass, remove excess loads from UPS output. If, after repetitive overloads, the UPS is locked in the Bypass mode, remove excess loads from UPS output first. Then shut down the UPS and restart it.
Why is my Power Walker VFI 1000RM beeping and showing a warning code?
If the icon and the warning code are flashing on the LCD display and the alarm is sounding every second on your Power Walker UPS, and the EPO function is activated, set the circuit in closed position to disable EPO function. If line and neutral conductors of UPS input are reversed, rotate the mains power socket by 180° and then connect to the UPS system. Also, check if all batteries are connected well, in case the external or internal battery is incorrectly connected.
How to fix a Power Walker VFI 1000RM UPS with no indication?
If the Power Walker UPS shows no indication and alarm even though the mains is normal, check if the input power cord is firmly connected to the mains. Also, ensure that you plug the AC input power cord to AC input correctly, in case the AC input is connected to the UPS output.
General| Output Power | 900 W |
|---|---|
| Output Voltage | 200/208/220/230/240 VAC |
| Battery Type | 12 V / 9 Ah |
| Battery Recharge Time | 4 hours to 90% |
| Transfer Time | 0 ms |
| Communication | USB, RS-232, SNMP (optional) |
| Output Waveform | Pure Sine Wave |
| Operating Temperature | 0°C to 40°C |
| Capacity | 1000 VA |
| Output Frequency | 50/60 Hz |
| Form Factor | Rackmount |
Guidelines for safely transporting the UPS system in its original packaging to prevent damage.
Important environmental and placement considerations before installing the UPS unit.
Instructions for connecting appliances and wiring the UPS system to a power source.
Key precautions and procedures for operating the UPS system safely and correctly.
Warnings and procedures related to maintenance, service, and handling of faults.
Identification and description of connectors and ports on the rear panel of the UPS.
Steps for mounting the UPS unit into a standard 19-inch rack chassis.
Detailed steps for connecting battery wires, input power, outputs, and communication.
Procedure for safely replacing the internal batteries of the UPS unit.
Instructions for assembling external battery kits for extended runtime.
Explanation of the functions for each button on the UPS front panel.
Overview and interpretation of the information displayed on the UPS LCD screen.
Description of the different audible alarm sounds and their meanings.
Glossary of abbreviations and display content shown on the LCD panel.
Guide to configuring various UPS parameters via the LCD interface.
Reference codes and descriptions for various fault events that may occur with the UPS.
Visual and audible indicators used to signal warnings and operational status of the UPS.
Notes on UPS operation, battery service life, and when to contact the dealer for replacement.
Guidelines for storing the UPS, including charging and environmental conditions.
