Power Wheels F-150 - Assembly - Undercarriage; Securing Underside Components

W1070pr-0920
11
•Carefullyturnthevehicleover.
•Insertfourscrewsintotheundersideofthevehicle
and into the cargo bed. Tighten the screws.
12
•Fitthesteeringcolumncapontotheendofthe
steering column.
Steering Column Cap
Screws
13
BOTTOM BACK VIEW
BOTTOM FRONT VIEW
•Fitthetabsonthegrillesupportthroughtheslotsin
the grille. Push to "snap" the tabs in place.
15
•Insertascrewthroughthelargeopeninginthe
steering column cap and the hole in the steering
column. Tighten the screw.
Grille Support
Tab
Screw
Tab
Slots
14
ASSEMBLY
