Power Wheels F-150 - Assembly - Wheels and Axles; Installing Rear Wheels and Clips

W1070pr-0920
12
•Insertfourscrewsintothegrillesupportandtighten.
•Alignthepegsontheundersideofthegrillesupport
with the posts on the vehicle.
•Inserttwoscrewsintothegrillesupportandtighten.
16
17
•Slidearearwheelontotherearaxle.
Hint: Note the number on the inside of the wheel and on
the bottom of the vehicle near the rear axle. The rear
wheel with a 1 should match the 1 on the vehicle and the
rear wheel with a 2 should match the 2 on the vehicle.
18
Rear Wheel
Rear Axle
2
ASSEMBLY
•Slidetheclipsothatthestraightendgoesthroughthe
other hole in the axle.
•Makesurethestraight end of the clip is through both
holes in the axle.
19
20
•Positionthewireclipsothatthewavysideisout.
•Insertthestraightsideoftheclipthroughtheholein
the axle.
BOTTOM SIDE VIEW
Screws
Screws
