POWERAMP
®
• Division of Systems, Inc. • W194 N11481 McCormick Drive • Germantown, WI 53022
800.643.5424 • fax: 262.257.7399 • www.poweramp.com • techservices@poweramp.com
Printed in U.S.A.
Copyright ©
2017
Manual No. 4111-0008
April 2017
June 2017
VS SERIES
Dock Leveler
Owner’s/User’s Manual

Table of Contents

Questions and Answers

  • C
    Charles DavisAug 19, 2025
    What to do if the Poweramp Laser Level platform does not rise and the pump operates in pressure relief mode?
    • A
      Anthony ConradAug 19, 2025
      If the platform of your Poweramp Laser Level doesn't rise and the pump operates in pressure relief mode, it might be due to a heavy object on the platform. Remove any objects, as the leveler is designed to lift only its own weight for safety reasons. Another cause could be the dock leveler binding; check for and remove any visible obstructions. If you find no obstructions, the pressure relief might be set too low, and you should increase it. Ensure that increasing the pressure relief doesn't cause the motor operating current to exceed the full load amp value.
  • J
    Joseph HarrisAug 21, 2025
    What to do if the Poweramp Laser Level platform does not rise or lower and the motor does not energize?
    • P
      perryhillAug 21, 2025
      If your Poweramp Laser Level platform doesn't rise or lower and the motor doesn't energize, it could be due to a tripped motor overload device or a blown fuse. Try resetting the overload relay (for three-phase units) or replacing the fuse(s) (for single-phase units). Be sure to determine the cause of the overload and use the same specification for the new fuse. It may also be caused by the motor starter (three-phase) or motor relay (single-phase) not energizing. Check the voltage at the starter or relay coil. If voltage is present but the starter or relay doesn't energize, replace it. If there's no voltage, inspect all components in series with the starter or relay coil.
  • K
    Kimberly TurnerAug 23, 2025
    What to do if the single-phase Poweramp VS platform does not rise or lower, but the motor energizes?
    • K
      Kelli ParrishAug 25, 2025
      If the platform of your single-phase Poweramp Laser Level does not rise or lower but the motor energizes, several issues could be the cause. First, check the wiring to the motor for high resistance, loose connections, or corrosion. Also, make sure the wire gauge is correct for the load. Replace the wiring if necessary. The motor centrifugal switch or the motor capacitor could also be defective, requiring motor replacement.
  • H
    Haley VillaAug 26, 2025
    Why is the Poweramp VS Laser Level platform rising slowly?
    • Z
      zachary35Aug 26, 2025
      If the platform of your Poweramp Laser Level rises slowly, it could be due to several reasons. You may have low hydraulic fluid, so add fluid as needed. The hydraulic system might be contaminated, requiring you to clean and inspect the valves, flush the system, and refill it with new oil. Also, check for damaged or restricted hydraulic hoses and replace them or remove the restriction. Finally, the pressure relief might be set too low, so increase it, ensuring that the motor operating current does not exceed the full load amp value.
  • J
    Jessica LevineAug 27, 2025
    What to do if the three-phase Poweramp VS Laser Level platform does not rise or lower, and the motor hums?
    • J
      James MooneyAug 28, 2025
      If your three-phase Poweramp Laser Level platform doesn't rise or lower, and the motor hums without running, it could be due to a lack of voltage on one line. Check for blown fuses at the branch circuit disconnect and replace any blown fuses. Determine what caused the fuse to blow. You can also check the motor starter. Disconnect the wires at the load side of the starter, energize the starter, and measure the line-to-line voltage at both the line and load sides. The voltages should be similar. If they differ significantly, replace the starter. Check all wiring to the motor for high resistance or no connection.
  • D
    danny11Aug 30, 2025
    Why does the Poweramp VS Laser Level pump motor load down when the platform starts to raise?
    • L
      Logan McleanAug 30, 2025
      If the pump motor of your Poweramp Laser Level loads down when the platform starts to raise from the lowered position, it could be because the pressure relief is set too high. Decrease the pressure relief, but make sure the adjustment doesn't cause the motor operating current to exceed the full load amp value.
  • B
    Blake StanleySep 1, 2025
    What causes the Poweramp VS platform to not rise to full height?
    • D
      Dr. Rick TorresSep 1, 2025
      If the platform of your Poweramp Laser Level does not rise to its full height, it could be due to low hydraulic fluid. Add fluid as needed. Another possible cause is the coil being energized on the float coil; remove the wire from the terminal strip to the float coil. If the leveler then raises, the PLC or relay might be bad. Also, a bad spool valve could be the issue; remove and clean it or replace it with a new or good working valve.
  • J
    Jeffrey Hughes PhDSep 3, 2025
    What causes the lip of the Poweramp Laser Level to not extend?
    • T
      Timothy LoveSep 3, 2025
      If the lip of your Poweramp Laser Level does not extend, the “C” Coil might not be energized. Check the power to the spool valve; it should have a magnetic pull when energized, and the pump motor must be running. It could also be a bad spool valve, in which case you should remove and clean it or replace it with a new or good working valve, making sure the pump motor is running.
  • E
    emilydavisSep 5, 2025
    Why does the lip of my Poweramp VS Laser Level not lower?
    • H
      huffbrentSep 5, 2025
      If the lip on your Poweramp Laser Level doesn’t lower, it could be because the “C”, “D”, and “E” Coils are not energized. All three valves must be energized, so check the power to all spool valves to ensure they have a magnetic pull, and the pump motor must be running. Another potential cause is a bad spool valve. In this case, remove and clean the spool valves or replace them with new or good working valves, ensuring the pump motor is running.
  • J
    Joshua OlsenSep 7, 2025
    How to fix the Poweramp Laser Level platform if it doesn't rise and the motor runs in reverse?
    • D
      deanfrancisSep 8, 2025
      If your three-phase Poweramp Laser Level platform doesn't rise and the motor runs in reverse, the phase might be reversed. To correct this, reverse any two legs at the branch circuit disconnect.

Summary

Precautions

Recognize Precautionary Information

Explains safety alert symbols, DANGER, WARNING, CAUTION, and NOTICE for hazard identification.

General Operational Precautions

Emphasizes reading the manual, familiarizing with controls, and keeping the operating zone clear.

Operational Precautions

Details safe operation practices like staying clear of moving parts and ensuring proper lip overlap.

Maintenance Precautions

Outlines safety measures for servicing, including power lockout and avoiding grinding/welding with fluids.

Precautionary Decals

Illustrates and explains various safety decals found on the equipment for user awareness.

Owners;Users Responsibilities

Introduction

General Information

Introduces the VS Vertical Storing hydraulic dock leveler and its benefits.

Dock Leveler Stock Specifications

Lists available models, sizes, weight capacities, and options for VS dock levelers.

Component Identification

Identifies key components of the dock leveler with labels and a list.

Installation

Prepare Pit

Details required pit dimensions and preparation steps, including safety warnings.

Prepare Dock Leveler

Instructions for preparing the dock leveler for installation, including lifting brackets and props.

Install Dock Leveler

Details the process of shimming and welding the embed channel for pit installation.

Install Control Panel and Wiring

Steps for mounting the control panel, disconnect panel, and connecting wiring.

Placard Installation Instructions

Guidance on the proper installation and placement of product placards.

Put New Dock Leveler Into Service

Steps to commission the dock leveler after installation, including purging and testing.

Purging Air From The VS Hydraulic System

Detailed procedure for removing air from the hydraulic system.

Rod Eye adjustment & New installation

Instructions for adjusting the rod eye and related steps for new installations.

Operation

Theory

Explains the basic operating principles of the electric motor and hydraulic pump.

Operating Instructions

General safety precautions and operational limits for using the dock leveler.

Ramp Loading;Unloading Instructions

Step-by-step guide for loading/unloading using the ramp method.

Below Dock End Loading;Unloading Instructions

Instructions for end loading/unloading when the vehicle is below dock level.

Maintenance

Service Dock Leveler

General safety precautions and procedures for servicing the dock leveler.

Periodic Maintenance

Information on recommended hydraulic fluids for optimal operation and warranty.

Checking Fluid Levels on Reservoir for Remote Pumps

Procedure for checking and maintaining hydraulic fluid levels in the reservoir.

Adjustments

Adjust Unit Pressure

Steps for adjusting pressure relief on the unit, including safety precautions.

Stored Limit Switch Adjustment

Instructions on how to adjust the stored limit switch for proper prop engagement.

Down Speed Control Adjustment

Guidance on adjusting the down speed control for the leveler's descent.

Storage Prop Adjustment

Details on adjusting the storage prop for correct play and thread exposure.

Troubleshooting

Troubleshooting

Initial checks before detailed troubleshooting, including fuses and voltages.

Parts

Storage Limit Switch

Lists parts and descriptions for the storage limit switch assembly.

Solenoid Prop Kicker and J-Box

Lists parts for the solenoid prop kicker and J-Box components.

Storage Prop Assembly

Lists parts and descriptions for the storage prop assembly.

Lip and Platform

Part number tables for vertical lips and platforms.

SC Vertical Leveler Hydraulic Components

Diagram and parts list for SC Vertical Leveler hydraulic components.

Centra Power Hydraulic Components

Diagram and parts list for Centra Power hydraulic components.

Centra Power KS4 Hydraulic Components

Diagram and parts list for Centra Power KS4 hydraulic components.

VS Manifold

Diagram and parts list for the VS Manifold.

VS Manifold CP W;O Powerhold

Diagram and parts list for the VS Manifold CP W/O Powerhold.

VS Manifold Remote W; Powerhold

Diagram and parts list for the VS Manifold Remote W/ Powerhold.

Platform Cylinder Repair Parts

Diagram and parts list for platform cylinder repair.

Lip Cylinder Repair Parts

Diagram and parts list for lip cylinder repair.

Remote Mount Power Pack Assembly

Diagram and parts list for the remote mount power pack assembly.

Power Pack Assembly

Diagram and parts list for the power pack assembly.

Miscellaneous

Customer Information

Form for recording dock leveler details and contact information for service.

Standard Product Warranty

PRODUCT SPECIFIC WARRANTY VS SERIES LEVELER

Outlines the extended structural and hydraulic warranty for the VS series.
