PowerBoss PB45LPG - Technical Specifications

TECHNICAL SPECIFICATIONS
Model Nautilus Rider Scrubber/Sweeper
Model No. PB450DSL, PB450GAS, PB450LPG
General Machine Specifications
Length:. . . . . . . . . . . . . . . . . . . . . . . . . . .95.00 in
Width with side scrub brush retracted: . . 60.50 in
Width with side scrub brush extended:. . 65.50 in
Height to lowest steering position. . . . . . 60.50 in
Height w/overhead guard . . . . . . . . . . . . 83.50 in
Wheelbase:. . . . . . . . . . . . . . . . . . . . . . . 47.75 in
Front tires: . . . . . . . . . . . . . . . . . . . . . . . .16 in x 6 in molded
Rear tires: . . . . . . . . . . . . . . . . . . . . . . . . 18 in x 5 in press on
Aisle width U-turn: . . . . . . . . . . . . . . . . . .8 ft - 11.7 in
Empty vehicle weight . . . . . . . . . . . . . . . 3,250 lbs
Gross vehicle weight . . . . . . . . . . . . . . . .4,800 lbs
Maximum forward speed: . . . . . . . . . . . . 7.7 mph
Maximum reverse speed: . . . . . . . . . . . . 4.0 mph
Maximum climb angle (Traveling):. . . . . .10 degrees
Maximum climb angle (Scrubbing):. . . . . 8 degrees
Scrubbing system
Cleaning path (main brushes) . . . . . . . . 45 in
Cleaning path (w/optional side brush) . . 60 in
Main brush diameter:. . . . . . . . . . . . . . . .12 in
Main brush length:. . . . . . . . . . . . . . . . . .45 in
Main brush speed:. . . . . . . . . . . . . . . . . .425 RPM
Main brush force:. . . . . . . . . . . . . . . . . . .200 lb - 400 lb
Side scrub brush diameter:. . . . . . . . . . . 16 in
Side scrub brush speed:. . . . . . . . . . . . . 200 RPM
Solution Tank capacity:. . . . . . . . . . . . . . 105 gal
Recovery Tank capacity:. . . . . . . . . . . . . 105 gal
Demister chamber capacity:. . . . . . . . . . 17 gal
(2) Debris trays, total capacity:. . . . . . . . 2.1 cu ft
Vacuum fan speed:. . . . . . . . . . . . . . . . . 11,500 RPM
Vacuum water lift: . . . . . . . . . . . . . . . . . .35 in
4
TECHNICAL SPECIFICATIONS
