Page #13 background imageLoading...
Page #13 background image
10HP - 20HP Scroll Enclosure Air Compressors
BRANCH CIRCUIT PROTECTION TABLE
Pg 13
(A) Load Specifications
System Type
Motor Size
(HP) Each
(A) Power
(V/PH)
(A) Motor
Load Each
(FLA)
Panel Load
Total
(FLA)
10HP System 5 (x2) 208V/3 14.2 31
5 (x2) 230V/3 12.8 29
5 (x2) 460V/3 6.4 15
5 (x2) 575V/3 5.1 13
15HP System 5 (x3) 208V/3 14.2 45
5 (x3) 230V/3 12.8 41
5 (x3) 460V/3 6.4 21
5 (x3) 575V/3 5.1 18
20HP System 5 (x4) 208V/3 14.2 60
5 (x4) 230V/3 12.8 54
5 (x4) 460V/3 6.4 28
5 (x4) 575V/3 5.1 23
(B) Branch Circuit Protection
(provided by installer)
Non-time
Delay Fuse
Time
Delay
Fuse
Inverse Time
Circuit
Breaker
60A 45A 60A
60A 40A 50A
30A 20A 25A
25A 20A 20A
75A 60A 70A
70A 50A 60A
35A 30A 35A
30A 25A 25A
90A 70A 80A
80A 65A 75A
45A 35A 40A
35A 30A 35A
