Take note of the following illustrations:
Fig. 1
Fig. 2
The further you are standing from the wall, the wider the area (a) is that the Distance Meter must
measure by ultrasound (Fig. 2)
.
Therefore, make sure that the distance meter is always pointed at a
right angle towards a level surface (Fig. 1 and 3). Ensure that there are no objects positioned
within the measurement area.
False!
Fig. 3
Notice
Inaccurate measurements can also occur because of a weak battery. If the battery is too weak,
the battery symbol appears in the display.
5 m
a
=
ca. 1,5 m
12 m
a
=
ca. 3,6 m
MIN. 0,5 m
MAX. 12 m
- 4 -
