PowerLand Generator User Manual

Item Part Qty Description Item Part Qty Description
1 1 Gasoline engine 42 14400 1 Fuel sensor
2 15100 1 Frame comp 43 GB 819-95 2
Screw M5×10
3 15002 2 Bottom rubber A 44 14410 1 Casket fuel tank
4 15003 2 Bottom rubber B 45 GB5787-86 4
Flange bolt M6×22
5 GB6177-86 12 Flange nut M8 46 14022 4 Washer
6 GB802-88 4 Flange nut M6 47 14005 4 Collar
7 41350 4 Cushion, frame 48 14001 4 Cushion
8 GB5787-86 4
Bolt M6×12
49 14004 1
Outlet pipeφ4.5×165
9 15001 2 Rubber pad, frame 50 14006 2 Tube clip
10 15201 2 Hand push 51 14003 1 Rubber, fuel tube
11 11010 1 Earth terminal set 52 14100 1 Fuel cock
12 GB5787-86 8
Flange bolt M6×12
53 13001 1 Protector comp muffler
13 11070 1 Receptacle (30A) 54 GB5787-86 4
Flange bolt M6×14
14 11092 1 Receptacle (20A) 55 GB5787-86 2
Flange bolt M8×32
15 11072 1 Receptacle (20A) 56 13010 1 Muffler stay
16 11120 2 Circuit protector 57 13020 1 Muffler
17 11090 1 Control panel 58 13002 1 Protector muffler inner
18 11110 1 Voltmeter 59 GB5789-86 4
Flange bolt M8×16
19 11050 2 Diode assay 60 13004 1 Seal protector muffler
20 11082 1 Engine switch 61 13005 1 Muffler, stay comp
21 11040 1 Boot, switch wire 62 13003 1 Protector muffler side
22 11030 1 Boot, main wire harness 63 11091 1 Control panel case
23 11010 1 Boot, AC output wire 64 11101 2 DC output post
24 11060 1 Wire harness Assy. 65 21000 1 Wheel Assy.
25 GB5787-86 2
Flange bolt M5×12
66 21050 2 Pin.
26 16004 1 Generator end cover 67 GB97.1-85 2
Washer φ20
27 GB5789-86 4
Flange bolt M6×175
68 21040 2 Wheel comp
28 16003 1 Support stand 69 21020 2 Bracket
29 GB5789-86 1
Bolt M10×1.25×265
70 21010 1 Well shaft
30 GB9701-85 1
Plain washerφ10
179 20053 1 Fuse
31 GB276-89 1 Bearing 6207-2RS 180 22001 1 Positive wire of battery
32 16200 1 Rotor comp 181 22002 1 Negative wire of battery
33 16000 1 Stator & Rotor Assy. 182 22005 1 Battery cover
34 16005 1 Generator fan 183 22010 1 Battery
35 16101 1 Stator cover
184 13030 1 Brush assy.
36 16100 1 Stator Assy.
185 13040 1 Voltage regulator
37 14201 1 Stripe, fuel tank
38 14200 1 Fuel tank
39 14302 1 Fuel filter
40 14303 1 Packing ring
41 14300 1 Fuel filler cap comp
