PowerLand Generator User Manual

Item Part Qty Description Item Part Qty Description
71 21100 1 Starter comp, recoil 112 11219 1 Casket, cylinder head
72 GB5787-86 3
Flange bolt M6×8
113 11218 2
Bolt head, 8×106
73 12310 1 Fan, cover comp 114 23008 2 Packing, air cleaner
74 GB5787-86 13
Flange bolt M6×12
115 22000 1 Stay assy. Manual choke
75 19003 1 Shroud comp 116 12012 1 Grommet fender
76 12302 3 Clip. Wire darkness 117 23000 1 Carburetor assy.
77 12302 1 Grommet drain hole 118 23002 1 Packing, carburetor
78 21000 1 Start motor 119 23001 1 Insulator, carburetor
79 GB5789-86 2
Flange bolt M8×35
120 GB6177-86 4 Flange nut M6
80 GB6177-86 1 Flange nut M16 121 12006 1 Stay, air cleaner
81 19005 1 Pulley, starter 122 12005 1 Case comp, air cleaner
82 19001 1 Fan, cooling 123 12004 1 Separator, air cleaner
83 GB/T 99-88 1 Key 124 GB6177-86 6 Flange nut M5
84 81200 1 Flywheel comp 125 12007 1 Cover comp, air cleaner
85 12215 2
Oil seal, 35×52×8
126 12008 2 Clip, air cleaner ware
86 12200 1 Crank case assy. 127 12003 1 Element, air cleaner
87 87500 1 Amplifier 128 12010 1 Seal, air cleaner
88 12203 2 Bolt, drain lug 129 23003 1 Packing, insulator
89 12217 2 Washer, drain lug 130 23011 4 Clip, tube
90 87601 1 Clip, wire 131 23006 1 Valve, dashpot check assy
.
91 21012 1 Protect board A 132 91009 1
Tube, fuel φ45×165
92 GB5789-86 4
Flange bolt M6×30
133 12001 1 Tube, breather
93 GB5789-86 2
Flange bolt M6×25
134 GB5789-86 4
Flange bolt M10×80
94 21011 1 Protect board B 135 11250 1 Head comp, cylinder
95 21000 1 Coil assy. excitation 136 11217 2
Bolt head, M8×34
96 22000 1 Coil assy. AC 12V (10A) 137 11202 1 Plug, spark
97 81102 1 Cord stop switch 138 15100 1 Camshaft assy.
98 81103 1 Grommet cord 139 15002 2 Lifter, valve
99 81100 1 Coil assy. ignition 140 11208 1 Valve, IN.
100 12216
Oil seal, 8×14×5
141 11209 1 Valve, EX.
101 GB/T276-94 2 Radial ball bearing (6202) 142 11216 1 Seat, valve spring
102 12208 1 Shaft, governor arm 143 11212 1 Retainer, EX. Valve spring
103 12212 1 Pin, lock, 10mm 144 11213 1 Rotator, valve
104 12209 1
Washer, 8.2×17×0.8
145 11211 1 Retainer, IN. Valve spring
105 GB6177-86 1 Flange nut M10 146 11206 2 Spring, valve
106 12221 1 O-ring,14mm 147 15001 2 Rod, push
107 12200 1 Switch assy. oil level 148 11241 1 Exhaust piper
108 13200 1 Weight, balancer 149 11240 1 Cover comp, head
109 13000 1 Crankshaft comp 150 11243 1 Washer comp head cover
110 GB/T276-94 2 Radial ball bearing (6207) 151 11242 1 Bolt, head cover
111 12220 2
Pin, dowel, 12×20
152 GB6175-86 2 Nut M8
