PowerLand PD3000 User Manual

SPECIFICATIONS
Item PD2000 PD4000E PD6500E
Rated Wattage 1200 W 3200 W 5500 W
Surge Wattage 1500 W 4000 W 5500 W
Rated Voltage 120 V 120/240 V
Rated Frequency 60 Hz
Phase Single
Generator
DC Output DC 12V/8.3 A
Engine type 4-stroke OHV single cylinder with forced air cooling system
Ignition system Transistorized magneto
Spark Plug
NGK BPR 6ES, F7RTC
Engine Speed
3600 rpm
Compression Ratio
7.0 : 1 8.5 : 1 8.0 : 1
Displacement 87 cc 196 cc 389 cc
Starting type Recoil Electric start /Recoil
Fuel tank capacity: 1.45 US gal. (5.5L) 3.96 US gal. (15L) 6.6 US gal. (25L)
Oil capacity 0.42 US qt (0.4 L) 0.63 US qt (0.6 L) 1.2 US qt (1.1 L)
Engine oil grade SAE 10W30 SG or SF
Valve Clearance
Intake 0.10-0.15 mm (0.004 – 0.006 in.)
Exhaust 0.15-0.20 mm (0.006 – 0.008 in.)
Engine
Noise Level 68 dB@7m (22 feet) 72 dB@7m (22 feet) 75 dB@7m (22 feet)
Dimensions (in): 18.7 "X15.6 "X16.7 "
24.8"×18.5"×19.5" 30.2"×22.5"×24.2"
Item PD8500E PD10000E
Rated Wattage 7000 W 8000 W
Surge Wattage 8500 W 10000 W
Rated Voltage 120/240 V
Rated Frequency 60 Hz
Phase Single
Generator
DC Output DC 12V/8.3 A
Engine type 4-stroke OHV single cylinder with forced air cooling system
Ignition system Transistorized magneto
Spark Plug
NGK BPR 6ES, F7RTC
Engine Speed
3600 rpm
Compression Ratio
8.0 : 1
Displacement 419 cc
Starting type Electric start /Recoil
Fuel tank capacity: 6.6 US gal. (25L) 8.3 US gal. (31.5L)
Oil capacity 1.2 US qt (1.1 L)
Engine oil grade SAE 10W30 SG or SF
Valve Clearance
Intake 0.10-0.15 mm (0.004 – 0.006 in.)
Exhaust 0.15-0.20 mm (0.006 – 0.008 in.)
Engine
Noise Level 75 dB @ 7 m (22 feet)
Dimensions (in):
30.2 "×22.5 "×24.2 "
30.3"X28.7"X25.2"

PowerLand PD3000 Specifications

General

Brand	PowerLand
Model	PD3000
Category	Portable Generator
Language	English
