ENG - 13Questions? Call Toll Free at 1-800-737-2112 Copyright © 2018 MAT Engine Technologies, LLC
Operation (Continued)
• Save all instructions
Stop the Engine
C
1. Press ON/OFF switch to OFF position.
Operating Speed
D
This tiller is equipped with a fixed throttle that is set for optimum tilling performance.
Shutting Down
E
To stop the engine at any time, release the clutch lever and press ON/OFF switch to OFF position. To stop tines at any
time, release clutch lever.
Transport Mode and Tilling Mode
F
Transport mode
Fold the wheel under the engine for convenient transport.
When transporting the unit, rotate the wheel assembly
forward under the engine and move by pulling the unit
rearward. This will keep the transport wheels locked into
position. (Fig 15)
NOTE: The drag bar must be in the middle or bottom hole
for transporting.
Tilling mode
Unfold the wheel back for tilling operation. (Fig 16)
Figure 14
Figure 15
Figure 16
