4 Owner’s Manual for Portable Generator
Section 2 General Information and Setup
Figure 2-1. Features and Controls
Generator Components
Figure 2-2. Control Panel
1
5
2
3
4
6
7
010381
010380010378
8
1 Control Panel
2 Spark Plug Access Cover
3 Recoil Handle
4 Engine Control Switch / Fuel Valve
5 Fuel Cap and Vent
6 Engine Service Panel
7 Muffler and Spark Arrestor
8 Choke Lever
9 120V Receptacle
10 Neutral Floating Grounding Location
11 Low Oil LED (Yellow)
12 Overload LED (Red)
13 Output ready LED (Green)
14 AC 9 Amp Circuit Breaker
