PowerMax PMTS-30 User Manual

Name: PowerMax PMTS-30
Brand: PowerMax
Rating: 5 (1 reviews)

3 pages

To Previous Page

PMTS-30

PMTS-50

Wiring to Control

Panel

Wiring from Shore

Power

Wiring from

Generator

All Grounds

connect here

Wiring from

Generator

1∅ L1, Neut

2∅ L1, Neut, L2

Wiring from Shore

Power

1∅ L1, Neut

∅

L1, Neut, L2

Wiring to Control

Panel

1∅ L1, Neut

∅

L1, Neut, L2

All Grounds

connect here
