4. Use 5# inner hexagon wrench, screw M8*42, nut M8 and Washer φ8 to lock the massage
pipe on the Columns (Picture A). Then use the decorative covers to cover the screws (Picture
B). (Install the massage pipe with foams under the one without the foam.)
5. Use 5# inner hexagon wrench and screw M8*55 to fix the massage pipe on the massage
frame, and tighten it with nut M8.
6. Remove the three M8*15 screws from the massage, and then use M8 * 15 screws to fix the
massage in the massage frame and put the belt on the massager.
To Next Page
