5
WARNING: It is not necessary to hit the Nailer hard
to activate it. Never hit the Nailer with excessive
force or with the metal end of the mallet, this will
damage the Nailer.
Never use the Safety Trigger interlock to lock up
the plunger and rack the wood with blows to the
Nailer body. This will severely damage the safety
mechanism and Nailer. This abuse and damage is not
covered by the warranty.
Before each use check all screws to be sure they are
tight. Shock and vibration can loosen screws. Do not
over tighten any screw.
AIR SUPPLY:
The air must be clean and dry. Dirty and/or wet
air will damage the Nailer. A combination fi lter-
regulator-lubricator is required for proper Nailer
performance and should be placed close to the Nailer
per manufacturer’s recommendations.
The air source must continuously deliver 80 to 110
psi at 3-1/2 cubic feet of air per minute to operate the
Nailer. Connect a clean air hose and air regulator to
the Nailer.
Check for air supply leaks that waste air and starve
the Nailer of air thereby reducing its performance.
LUBRICATION:
If you do not use an in line lubricator, you must
lubricate the Nailer manually. The frequency of
lubrication is dependent upon the duty cycle of the
Nailer. Continuous duty requires more frequent
oiling than intermittent duty.
At least every eight (8) hours place two to four
drops of Pneumatic Light Air Tool Oil into the
disconnected air line male connector attached
to the Nailer.
WARNING: Detergent oil is not
recommended and may damage the seals.
WARNING: Do not over lubricate the Nailer, excess
oil mist or drops will be vented with spent air when
over lubricated. Excess oil could stain the wood
fl ooring, walls or furnishings. Dry fi re the Nailer,
without nails, to purge excess oil, before you begin to
nail down fl ooring. We will not be responsible for oil
stains. Before storing the Nailer, lubricate and cycle
the Nailer in insure internal parts are oil protected
from corrosion.
PARTS & SERVICE:
When ordering parts include the part number, part
description, Powernailer model and serial number.
Be sure to state the quantity of the part(s) required.
Contact your Powernail Dealer for the necessary parts
or service.
WARNING: Never work on the Nailer if the air line
is attached. Always disconnect the air line from the
Nailer fi rst.
NAILER DISASSEMBLY:
TO REPLACE RUBBER BUMPER (#31):
1. Disconnect the air supply
2. Remove the four (4) cap screws holding the Adapter
Foot, Foot and Nail Channel assembly to the main
Body
(see illustration).
3. Pull the Rubber Bumper out of the cylinder bore.
Replace the old Bumper if it shows signs of wear or it
is split.
4. Reverse these steps to reassemble the Nailer. Be
sure to align the Driving Blade with the slot in the
Nail Channel Assembly while you reassemble the
Nailer. NEVER FIRE THE NAILER WITHOUT
THE RUBBER BUMPER INSTALLED, IT WILL
DAMAGE THE NAILER.
OPERATION, continued...
For Step-by-Step Videos and Instructions,
Visit our Web Site at: www.Powernail.com
FLEX Foot
Adjustment Video
Service and
Maintenance Videos
