POWERPATH PS-8-LP - Page 22

P84905-002 A Sheet 22 of 37
□
■ ■ □ ■ □
AUX Output Current Limit Reduce the number of NAC Appliances on Output1
□ ■ ■ ■ □ □
SYNC BUS Short
Check for a wiring short. Check for improperly wired NAC
circuit. (If an appliance is wired + to – and – to + a short trouble
will be indicated.
□ ■ ■ ■ ■ □
SYNC BUS Open
Check SYNC BUS terminals for good connections. Check NAC
circuit wiring for continuity. Check NAC circuit for 10K Ohm
EOLR.
■ □ □ □ □ ■
SYNC BUS Current Limit
Excessive current on the SYNC BUS. Reduce the number of
Power Supplies connected to the circuit.
■ □ □ □ ■ ■
Dry Contact 1
Ground Fault
(Note 1)
Check for circuit wire to enclosure or conduit.
■ □ □ ■ □ ■
Dry Contact 2
Ground Fault
(Note 1)
Same as above
■ □ □ ■ ■ ■
NAC Output 1+
Ground Fault
(Note 1)
Same as above
■ □ ■ □ □ ■
NAC Output 1–
Ground Fault
(Note 1)
Same as above
■ □ ■ □ ■ ■
NAC Output 2+
Ground Fault
(Note 1)
Same as above
■ □ ■ ■ □ ■
NAC Output 2–
Ground Fault
(Note 1)
Same as above
■ □ ■ ■ ■ ■
NAC Output 3+
Ground Fault
(Note 1)
Same as above
■ ■ □ □ □ ■
NAC Output 3–
Ground Fault
(Note 1)
Same as above
■ ■ □ □ ■ ■
NAC Output 4+
Ground Fault
(Note 1)
Same as above
■ ■ □ ■ □ ■
NAC Output 4–
Ground Fault
(Note 1)
Same as above
■ ■ □ ■ ■ ■
AUX Output+
Ground Fault
(Note 1)
Same as above
■ ■ ■ □ □ ■
AUX Output–
Ground Fault
(Note 1)
Same as above
■ ■ ■ □ ■ ■
SYNC BUS+
Ground Fault
(Note 1)
Same as above
■ ■ ■ ■ □ ■
SYNC BUS-
Ground Fault
(Note 1)
Same as above
■ ■ ■ ■ ■ ■
Battery Wires
Ground Fault
(Note 1)
Same as above
Note 1: When LED indicator D3 is lighted, it indicates a general ground fault condition. Momentarily depress switch
SW5 (Ground Fault Detect Enable Pushbutton). The Coded Trouble LEDs will indicate the circuit location of the
ground fault.
FUSE REPLACEMENT PROCEDURE (All Models):
1. Turn off the AC Mains Power.
2. Open the enclosure and turn off DC battery power.
3. Remove F1.
4. Replace F1 with a 10A 250V fuse.
5. Remove F2.
6. Replace F2 with a 10A 250V fuse.
7. Turn on DC battery power.
8. Close the enclosure.
9. Turn on AC Mains.
