6
position by screwing into place, using the two fixing holes in the frame. To
locate the fixing holes, open the oven door and look inside. To allow adequate
ventilation the measurements and distances indicated must be adhered to.
The panels of the kitchen unit that are next to the oven must be heat
resistant. Remove the back of the kitchen unit to ensure an adequate current
of air circulates around the oven. The hob must have a rear gap of at least 45
mm.
Securing your oven to the cabinet
Connection the Oven
The wires in the mains lead are coloured as follows:
GREEN AND YELLOW: EARTH
BLUE: NEUTRAL
BROWN: LIVE
 Release the cover plate by removing the cover screw
 Fit oven into the cabinet recess
 Open the oven door
 Secure the oven to the kitchen
cabinet with two distance
Holders "A" which fit the holes
In the oven frame and fit
The two screws "B".
