CONTENTS
Technical data…...………………………………………………………... 3
Introduction………………………………………………………………. 4
Safety information…….………………………………………………... 4
General safety procedures ……....……………………………………… 5
Important safety instructions……………………………………………. 6
Symbols…………………………………….…….…….…….………..…. 9
Knowing your chipper shredder……………………….………………… 10
Assembly instruction………………………………………………...….. 12
Operation……………………....………………………………………… 14
Maintenance……………………………………………………………... 19
Transport&Storage……………………………………………………… 22
Troubleshooting…………………………………………………………. 23
Exploded view & parts list……………………………………………… 26
Warranty………………………………………………………………… 32
TECHNICAL DATA
Gas powered chipper shredder Model # PS1130
Engine type: 4 Stroke, OHV, single cylinder with forced air-cooling system
Spark plug gap: 0.027" - 0.031"(0.7-0.8 mm )
Displacement: 212cc
Fuel type: 87+ octane stabilizer-treated unleaded gasoline
Fuel tank capacity: 0.95 Gallon
Engine oil type: 10W-30
Oil capacity: 16.9 fl.oz
Horsepower: 7.0hp
Start type: Recoil
Cutting capacity: 3 inch
Hopper dimension: 17.7 x 13.9 inches
Wheel: 12 inch
Package dimensions (L x W x H): 33.5 x 23.8 x 23.8 inches
Weight: 132 lb.
