Powersmart V8622S - Page 23

23
E02-1 11411-Z2P0110-00A0
COVER,
CRANKCASE
1 E10-1 13501-Z010110-00A0
NUT,
FLYWHEEL
1
E02-2
90682-Z030320-0000
SEAL, OIL
1
E10-2
19352-Z2P0110-00A0
IMPELLER
1
E02-3 90001-0630-01 BOLT 7 E10-3 28020-Z2P0110-0000
SEAT,
STARTER CUP
1
E02-4 16400-Z2P0111-00A0
GEAR ASSY,
GOVERNOR
1 E10-4 13510-Z2P0110-00A0
FLYWHEEL
SUBASSEMBLY
1
E02-5 16013-Z030120-0000
PLATE,
GOVERNOR
SPINDLE
COMPRESSION
1 E10-5 30029-Z2P0110-0000
LUG，
SHROUD
1
E02-6
90001-0616-01
BOLT
1
E10-6
90007-0516-A1
BOLT
1
E02-7
90502-0812-00
PIN
2
E10-7
45200-Z2P0110-JS00
BRAKE ASSY.
1
E03-1 14081-Z2P0110-00A0
TAPPET,
VALVE
2 E10-8 90007-0520-A1 BOLT 3
E03-2 14071-Z2P0110-00A0 LIFTER, VALVE 2 E10-9 30400-Z2P0110-0000
COIL,
IGNITION
1
E03-3 12131-Z3C0110-00A0
GASKET,
CYLINDER
HEAD
1 F01-1 17001-Z2P0110-00A0
GASKET, AIR
CLEANER
1
E03-4 12140-Z3C0110-00A0
HEAD
SUBASSEMBLY,
CYLINDER
1 F01-2 17100-Z2P0110-0000 CLEANER, AIR 1
E03-5
90001-0850-01
BOLT
4
F01-3
90305-0600-31
NUT
2
E03-6 30010-Z120110-00A0 PLUG, SPARK 1 F01-4 17004-Z2P0110-0000
TUBE,
BREATHER
1
E03-7 12101-Z810210-00A0 GUIDE, SEAL 1 F02-1 90107-0413-03 BOLT 3
E03-8 12110-Z3C0110-00A0 VALVES SET 2 F02-2 18130-Z2P0210-0000
COVER,
MUFFLER
OUTER
1
E03-9
12103-Z030110-0000
SPRING, VALVE
2
F02-3
90001-0616-01
BOLT
2
E03-10 12112-Z010110-00A0
SEAT, VALVE
SPRING
2 F02-4 18100-Z2P0210-0000
MUFFLER
ASSY.
1
E03-11 14310-Z2P0110-00A0
ROCKER
SUBASSEMBLY,
VALVE
2 F02-5 18020-Z2P0110-00A0
PLATE,
MUFFLER
INSULATOR
1
E03-12 14330-Z2P0110-00A0
SHAFT, VALVE
ROCKER
1 F03-1 16600-Z2P0110-Q2A9
TANK ASSY,
FUEL
1
E03-13 12411-Z2P0110-0000
COVER,
CYLINDER
HEAD
1 F03-2 16744-Z620120-0000
TANK CAP
CHAIN
1
E03-14 90007-0512-A1 BOLT 4 F03-3 16730-Z620210-LKD0
COVER, FUEL
TANK
1
E04-1 13300-Z3C0910-00A0
CRANKSHAFT
ASSY.
1 F03-4 16652-Z030110-00A0
STRAINER，
FUEL
1
E04-2 14014-Z2P0210-00A0
GEAR, TIMING
DRIVE
1 F03-5 90685-1000-01 CLAMP 1
