8
NOTE: THE 6 HIGH CURRENT CONNECTORS INDICATED CANNOT EXCEED A
TOTAL OF 50 AMPS COMBINED.
1X (175A) High Current Connectors
• High Current Inverter Output
• Emergency 600A Jump Starter
Output (7 seconds)
• Connected directly to battery
WARNING:
• The Master switch does not
disconnect the battery from this
connector.
• This output is NOT Fused or Short
Circuit Protected.
• Do not jump start a vehicle for longer
than 7 seconds.
• Deep Cycle batteries should be
used for jump starting in emergency
situations ONLY, as it will aect the
battery life.
• Check battery specifications and
compatibility with high current draw
before using the jump start connector.
• Lithium batteries should not be used
for jump starting.
CONNECTIONS:
